PUMPA blue line 3PVM750-120 230V submersible screw pump 3", cable 40m + switch box

Submersible 3" pump for dug and drilled wells, for pumping clean water, irrigation. Stainless steel shaft, casing and hydraulics. Maximum immersion 40 m. See more

Technical Specifications

Maximum flow [l/min]
30
Maximum head [m]
120
Input voltage [V]
230
Power output - P2 [kW]
0,75

Show all Tech Specs

in stock >100 pcs

170.93 € VAT included

the price includes a recycling fee

Delivery accross EU within 2-4 days %

Brand:
PUMPA
Category:
Submersible borehole pumps
Product No.:
ZB00061165
Sale group:
CEBL
EAN:
8596455020417

Product variants

  • Technical Specifications
  • Product No.
  • Maximum flow [l/min]
  • Maximum head [m]
  • Input voltage [V]
  • Power output - P2 [kW]
  • Delivery port ["]
  • Pump diameter ["]
  • Maximum immersion depth [m]
  • Drinking water certificate
  • Float switch
  • Maximum current [A]
  • Maximum liquid temperature [°C]
  • Cable length [m]
  • Protection [IP]
  • Automatic thermal protection
  • Dry run protection
  • Off switch
  • Speed ​​control
  • Capacitor
  • Maximum borehole diameter [mm]
  • Construction
  • Availability
  • Price

next

Variant Product No.

Availability

Price (VAT incl.)

PUMPA blue line 3PVM750-120 230V submersible screw pump 3", cable 40m + switch box

Product No.: ZB00061165 Sale group: CEBL EAN: 8596455020417

in stock
>100 pcs
Product availability
  • central warehouse >100 pcs

170.93 €

Maximum flow [l/min]
30
Maximum head [m]
120
Input voltage [V]
230
Power output - P2 [kW]
0,75
Delivery port ["]
1
Pump diameter ["]
3
Maximum immersion depth [m]
40
Drinking water certificate
NO
Float switch
NO
Maximum current [A]
6,20
Maximum liquid temperature [°C]
35
Cable length [m]
40
Protection [IP]
68
Automatic thermal protection
YES
Dry run protection
NO
Off switch
YES
Speed ​​control
NO
Capacitor
external
Maximum borehole diameter [mm]
75
Construction
screw
You are viewing this variant

Product description

PUMPA Blue Line 3PVM Pump Application

  • For drilled wells from 100 mm
  • Pumping clean water for households
  • Water circulation in fountains
  • Rainwater irrigation
  • Pressure systems power supply
  • Filling and emptying tanks

PUMPA Blue Line 3PVM Pump Features

  • Fits into narrower wells (from 100 mm) and, compared to 4 "pumps, provides more space in the annulus, which prevents clogging with stones or other impurities
  • It can be used for smaller buildings water supply - capacity for both irrigation and shower, etc.
  • Quick and easy installation and maintenance
  • For dug and drilled wells

Instructions

Technical Specifications

Maximum flow [l/min]
30
Maximum head [m]
120
Input voltage [V]
230
Power output - P2 [kW]
0,75
Delivery port ["]
1
Pump diameter ["]
3
Maximum immersion depth [m]
40
Drinking water certificate
NO
Float switch
NO
Maximum current [A]
6,20
Maximum liquid temperature [°C]
35
Cable length [m]
40
Protection [IP]
68
Automatic thermal protection
YES
Dry run protection
NO
Off switch
YES
Speed ​​control
NO
Capacitor
external
Maximum borehole diameter [mm]
75
Construction
screw
