PUMPA blue line PTM80-1 230V volumetric pump, cable 0,3m

BLUE LINE PTM80 self-priming displacement pump designed for pumping clean water in irrigation systems with liquid temperatures up to 60°C. See more

Technical Specifications

Maximum flow [l/min]
60
Maximum head [m]
70
Input voltage [V]
230
Power output - P2 [kW]
0.75

Show all Tech Specs

in stock >50 pcs

101.71 € VAT included

the price includes a recycling fee

Delivery accross EU within 2-4 days %

Brand:
PUMPA
Category:
Horizontal surface pumps
Product No.:
ZB00001152
Sale group:
CEBL
EAN:
8596455001348

Product variants

  • Technical Specifications
  • Product No.
  • Maximum flow [l/min]
  • Maximum head [m]
  • Input voltage [V]
  • Power output - P2 [kW]
  • Suction port ["]
  • Power input - P1 [kW]
  • Delivery port ["]
  • Maximum suction lift [m]
  • Drinking water certificate
  • Maximum current [A]
  • Maximum liquid temperature [°C]
  • Protection [IP]
  • Automatic thermal protection
  • Dry run protection
  • Off switch
  • Speed ​​control
  • Capacitor
  • Pump design
  • Impeller material
  • Construction
  • Availability
  • Price

next

Variant Product No.

Availability

Price (VAT incl.)

PUMPA blue line PTM80-1 230V volumetric pump, cable 0,3m

Product No.: ZB00001152 Sale group: CEBL EAN: 8596455001348

in stock
>50 pcs
Product availability
  • central warehouse >50 pcs

101.71 €

Maximum flow [l/min]
60
Maximum head [m]
70
Input voltage [V]
230
Power output - P2 [kW]
0.75
Suction port ["]
1
Power input - P1 [kW]
1.10
Delivery port ["]
1
Maximum suction lift [m]
6
Drinking water certificate
NO
Maximum current [A]
5.50
Maximum liquid temperature [°C]
35
Protection [IP]
X4
Automatic thermal protection
YES
Dry run protection
NO
Off switch
NO
Speed ​​control
NO
Capacitor
integrated
Pump design
horizontal
Impeller material
brass
Construction
positive displacement
You are viewing this variant

Product description

Use of the pump PUMPA blue line PTM80

  • for pumping clean water
  • for irrigation

Benefits

  • thermal overload protection
  • copper winding

Instructions

Technical Specifications

Maximum flow [l/min]
60
Maximum head [m]
70
Input voltage [V]
230
Power output - P2 [kW]
0.75
Suction port ["]
1
Power input - P1 [kW]
1.10
Delivery port ["]
1
Maximum suction lift [m]
6
Drinking water certificate
NO
Maximum current [A]
5.50
Maximum liquid temperature [°C]
35
Protection [IP]
X4
Automatic thermal protection
YES
Dry run protection
NO
Off switch
NO
Speed ​​control
NO
Capacitor
integrated
Pump design
horizontal
Impeller material
brass
Construction
positive displacement
