GRUNDFOS MAGNA3 PN16 threaded circulator pump

The Grundfos MAGNA3 circulator pump is the premium choice when system control and monitoring is key. MAGNA3 supports fieldbus by optional CIM modules and has a TFT display for intuitive configuration of the intelligent features See more

Technical Specifications

Maximum flow [l/min]
116 - 200
Maximum head [m]
4 - 12
Input voltage [V]
230
Suction port ["]
6/4, 2

Show all Tech Specs

in stock 3 pcs

from 730.38 € VAT included

Choose variant

Delivery accross EU within 2-4 days %

Brand:
Grundfos
Category:
Heating pumps
Product No.:
MAS000477

Product variants

  • Technical Specifications
  • Product No.
  • Maximum flow [l/min]
  • Maximum head [m]
  • Input voltage [V]
  • Suction port ["]
  • Delivery port ["]
  • Maximum current [A]
  • Maximum liquid temperature [°C]
  • Protection [IP]
  • Dry run protection
  • Off switch
  • Speed ​​control
  • Capacitor
  • Impeller material
  • Port-to-port length
  • Availability
  • Price

next

Variant Product No.

Availability

Price (VAT incl.)

Grundfos MAGNA3 25-40 180mm 230V PN16

Product No.: ZB00030139 Sale group: CEGBB EAN: 5710626493241 Manuf. No.: 97924249

in stock
3 pcs
Product availability
  • central warehouse 3 pcs

730.38 €

Maximum flow [l/min]
116
Maximum head [m]
4
Input voltage [V]
230
Suction port ["]
6/4
Delivery port ["]
6/4
Maximum current [A]
0.46
Maximum liquid temperature [°C]
110
Protection [IP]
X4
Dry run protection
YES
Off switch
NO
Speed ​​control
YES
Capacitor
integrated
Impeller material
noryl
Port-to-port length
180

Grundfos MAGNA3 25-60 180mm 230V PN16

Product No.: ZB00002392 Sale group: CEGBB EAN: 5710626493258 Manuf. No.: 97924250

on demand
check availability
Product availability
  • central warehouse 0 pcs

867.47 €

Check availability

Maximum flow [l/min]
150
Maximum head [m]
6
Input voltage [V]
230
Suction port ["]
6/4
Delivery port ["]
6/4
Maximum current [A]
0.75
Maximum liquid temperature [°C]
110
Protection [IP]
X4
Dry run protection
YES
Off switch
NO
Speed ​​control
YES
Capacitor
integrated
Impeller material
noryl
Port-to-port length
180

Grundfos MAGNA3 25-80 180mm 230V PN16

Product No.: ZB00030140 Sale group: CEGBB EAN: 5710626493265 Manuf. No.: 97924251

on demand
check availability
Product availability
  • central warehouse 0 pcs

987.93 €

Check availability

Maximum flow [l/min]
166
Maximum head [m]
8
Input voltage [V]
230
Suction port ["]
6/4
Delivery port ["]
6/4
Maximum current [A]
1.02
Maximum liquid temperature [°C]
110
Protection [IP]
X4
Dry run protection
YES
Off switch
NO
Speed ​​control
YES
Capacitor
integrated
Impeller material
noryl
Port-to-port length
180

Grundfos MAGNA3 25-100 180mm 230V PN16

Product No.: ZB00030135 Sale group: CEGBB EAN: 5710626493272 Manuf. No.: 97924252

on demand
check availability
Product availability
  • central warehouse 0 pcs

1,083.76 €

Check availability

Maximum flow [l/min]
200
Maximum head [m]
10
Input voltage [V]
230
Suction port ["]
6/4
Delivery port ["]
6/4
Maximum current [A]
1.33
Maximum liquid temperature [°C]
110
Protection [IP]
X4
Dry run protection
YES
Off switch
NO
Speed ​​control
YES
Capacitor
integrated
Impeller material
noryl
Port-to-port length
180

Grundfos MAGNA3 25-120 180mm 230V PN16

Product No.: ZB00030137 Sale group: CEGBB EAN: 5710626493289 Manuf. No.: 97924253

on demand
check availability
Product availability
  • central warehouse 0 pcs

1,218.19 €

Check availability

Maximum flow [l/min]
183
Maximum head [m]
12
Input voltage [V]
230
Suction port ["]
6/4
Delivery port ["]
6/4
Maximum current [A]
1.56
Maximum liquid temperature [°C]
110
Protection [IP]
X4
Dry run protection
YES
Off switch
NO
Speed ​​control
YES
Capacitor
integrated
Impeller material
noryl
Port-to-port length
180

Grundfos MAGNA3 32-40 180mm 230V PN16

Product No.: ZB00030144 Sale group: CEGBB EAN: 5710626493357 Manuf. No.: 97924260

on demand
check availability
Product availability
  • central warehouse 0 pcs

897.43 €

Check availability

Maximum flow [l/min]
133
Maximum head [m]
4
Input voltage [V]
230
Suction port ["]
2
Delivery port ["]
2
Maximum current [A]
0.61
Maximum liquid temperature [°C]
110
Protection [IP]
X4
Dry run protection
YES
Off switch
NO
Speed ​​control
YES
Capacitor
integrated
Impeller material
noryl
Port-to-port length
180

Grundfos MAGNA3 32-60 180mm 230V PN16

Product No.: ZB00030148 Sale group: CEGBB EAN: 5710626493364 Manuf. No.: 97924261

on demand
check availability
Product availability
  • central warehouse 0 pcs

1,049.83 €

Check availability

Maximum flow [l/min]
166
Maximum head [m]
6
Input voltage [V]
230
Suction port ["]
2
Delivery port ["]
2
Maximum current [A]
0.91
Maximum liquid temperature [°C]
110
Protection [IP]
X4
Dry run protection
YES
Off switch
NO
Speed ​​control
YES
Capacitor
integrated
Impeller material
noryl
Port-to-port length
180

Grundfos MAGNA3 32-80 180mm 230V PN16

Product No.: ZB00030151 Sale group: CEGBB EAN: 5710626493371 Manuf. No.: 97924262

on demand
check availability
Product availability
  • central warehouse 0 pcs

1,093.75 €

Check availability

Maximum flow [l/min]
183
Maximum head [m]
8
Input voltage [V]
230
Suction port ["]
2
Delivery port ["]
2
Maximum current [A]
1.19
Maximum liquid temperature [°C]
110
Protection [IP]
X4
Dry run protection
YES
Off switch
NO
Speed ​​control
YES
Capacitor
integrated
Impeller material
noryl
Port-to-port length
180

Grundfos MAGNA3 32-100 180mm 230V PN16

Product No.: ZB00030141 Sale group: CEGBB EAN: 5710626493388 Manuf. No.: 97924263

on demand
check availability
Product availability
  • central warehouse 0 pcs

1,188.92 €

Check availability

Maximum flow [l/min]
200
Maximum head [m]
10
Input voltage [V]
230
Suction port ["]
2
Delivery port ["]
2
Maximum current [A]
1.47
Maximum liquid temperature [°C]
110
Protection [IP]
X4
Dry run protection
YES
Off switch
NO
Speed ​​control
YES
Capacitor
integrated
Impeller material
noryl
Port-to-port length
180

Product description

MAGNA3 is an intelligent, high-efficiency circulator pump

The MAGNA3 circulator is a highly-advanced canned rotor pump intended for large commercial buildings such as hospitals and schools. Intelligent features such as AUTOADAPT and FLOWADAPT select the optimal system setting, ensuring that your system always provides the best possible comfort and the most efficient operation.

Connect the pump to a building management system and get complete control and monitoring of the system and improve reliability at the same time. You can also use the Grundfos GO Remote for monitoring purposes, giving you access to system data right at your fingertips.

MAGNA3 also offers multi-pump functionality, in which two pumps are connected in parallel. Multi-pump systems can operate in alternating, backup or cascade operation.

Save energy and time with intelligent control

Intelligent control modes such as AUTOADAPT result in significant energy savings.

Inputs and outputs ensure better system monitoring and optimal pump regulation.

MAGNA3 is an all-purpose circulator, ideal for applications such as heating, cooling and domestic hot water.

MAGNA3, More than a pump

The MAGNA3 is a circulator pump based on the tried and tested MAGNA technology and our industry-leading experience with electronic pumps. The permanent magnet motor, AUTOadapt function and integrated frequency converter is still part of the MAGNA package, but we’ve added some additional, ground-breaking new technologies. The result is a cutting-edge piece of intelligent technology that retains the unrivalled Grundfos reliability.

Instructions

Technical Specifications

Maximum flow [l/min]
116 - 200
Maximum head [m]
4 - 12
Input voltage [V]
230
Suction port ["]
6/4, 2
Delivery port ["]
6/4, 2
Maximum current [A]
0.46 - 1.56
Maximum liquid temperature [°C]
110
Protection [IP]
X4
Dry run protection
YES
Off switch
NO
Speed ​​control
YES
Capacitor
integrated
Impeller material
noryl
Port-to-port length
180
