WILO TWU 3" multistage submersible pump

Multistage 3" submersible pump in jacketed construction for vertical or horizontal installation See more

Technical Specifications

Maximum flow [l/min]
45
Maximum head [m]
45 - 130
Input voltage [V]
230
Power output - P2 [kW]
0.37 - 1.10

Show all Tech Specs

on demand check availability

from 798.58 € VAT included

Choose variant

Delivery accross EU within 2-4 days %

Brand:
WILO
Category:
Submersible borehole pumps
Product No.:
MAS000874

Product variants

  • Technical Specifications
  • Product No.
  • Maximum flow [l/min]
  • Maximum head [m]
  • Input voltage [V]
  • Power output - P2 [kW]
  • Delivery port ["]
  • Pump diameter ["]
  • Maximum immersion depth [m]
  • Drinking water certificate
  • Float switch
  • Maximum current [A]
  • Maximum liquid temperature [°C]
  • Cable length [m]
  • Protection [IP]
  • Automatic thermal protection
  • Dry run protection
  • Off switch
  • Speed ​​control
  • Capacitor
  • Maximum borehole diameter [mm]
  • Impeller material
  • Construction
  • Availability
  • Price

next

Variant Product No.

Availability

Price (VAT incl.)

WILO TWU 3-0115 230V submersible pump

Product No.: ZB00066914 Sale group: CEW05 EAN: 4016322781837 Manuf. No.: 4090889

on demand
check availability
Product availability
  • central warehouse 0 pcs

798.58 €

Check availability

Maximum flow [l/min]
45
Maximum head [m]
45
Input voltage [V]
230
Power output - P2 [kW]
0.37
Delivery port ["]
1
Pump diameter ["]
3
Maximum immersion depth [m]
60
Drinking water certificate
NO
Float switch
NO
Maximum current [A]
3.75
Maximum liquid temperature [°C]
35
Cable length [m]
1.80
Protection [IP]
58
Automatic thermal protection
YES
Dry run protection
NO
Off switch
YES
Speed ​​control
NO
Capacitor
external
Maximum borehole diameter [mm]
72
Impeller material
noryl
Construction
centrifugal

WILO TWU 3 - 0123 P 230V multistage submersible pump

Product No.: ZB00038537 Sale group: CEW05 EAN: 4016322782049 Manuf. No.: 4090890

on demand
check availability
Product availability
  • central warehouse 0 pcs

851.82 €

Check availability

Maximum flow [l/min]
45
Maximum head [m]
70
Input voltage [V]
230
Power output - P2 [kW]
0.55
Delivery port ["]
1
Pump diameter ["]
3
Maximum immersion depth [m]
60
Drinking water certificate
NO
Float switch
NO
Maximum current [A]
4.50
Maximum liquid temperature [°C]
35
Cable length [m]
1.80
Protection [IP]
58
Automatic thermal protection
YES
Dry run protection
NO
Off switch
YES
Speed ​​control
NO
Capacitor
external
Maximum borehole diameter [mm]
72
Impeller material
noryl
Construction
centrifugal

WILO TWU 3 - 0130 P 230V multistage submersible pump

Product No.: ZB00047937 Sale group: CEW05 EAN: 4016322782056 Manuf. No.: 4090891

on demand
check availability
Product availability
  • central warehouse 0 pcs

951.04 €

Check availability

Maximum flow [l/min]
45
Maximum head [m]
90
Input voltage [V]
230
Power output - P2 [kW]
0,75
Delivery port ["]
1
Pump diameter ["]
3
Maximum immersion depth [m]
60
Drinking water certificate
NO
Float switch
NO
Maximum current [A]
5,85
Maximum liquid temperature [°C]
35
Cable length [m]
1,80
Protection [IP]
58
Automatic thermal protection
YES
Dry run protection
NO
Off switch
YES
Speed ​​control
NO
Capacitor
external
Maximum borehole diameter [mm]
72
Impeller material
noryl
Construction
centrifugal

WILO TWU 3-0145 400V submersible pump

Product No.: ZB00066915 Sale group: CEW05 EAN: 4016322781820 Manuf. No.: 4090895

on demand
check availability
Product availability
  • central warehouse 0 pcs

1,038.16 €

Check availability

Maximum flow [l/min]
45
Maximum head [m]
130
Power output - P2 [kW]
1.10
Delivery port ["]
1
Pump diameter ["]
3
Maximum immersion depth [m]
60
Drinking water certificate
NO
Float switch
NO
Maximum current [A]
3.20
Maximum liquid temperature [°C]
35
Cable length [m]
1.80
Protection [IP]
58
Automatic thermal protection
YES
Dry run protection
NO
Off switch
NO
Speed ​​control
NO
Capacitor
NO
Maximum borehole diameter [mm]
72
Impeller material
noryl
Construction
centrifugal

Product description

Your advantages

  • Parts that come in contact with fluids are corrosion-free

  • Integrated non-return valve

  • Maintenance-friendly, rewindable motor



Construction

Multistage 3" submersible pump in jacketed construction for vertical or horizontal installation

Application

  • For private water supply from boreholes, wells and rainwater storage tanks

  • For domestic water supply, sprinkling and irrigation

  • For pumping water without long-fibre and abrasive constituents

Equipment/function

  • Multistage submersible-motor pump with radial impellers

  • Integrated non-return valve

  • NEMA coupling

  • Single-phase or three-phase AC motor

  • Integrated thermal motor protection for single-phase motor



Scope of delivery

  • Hydraulics + motor fully assembled

  • 1.8 m connecting cable approved for drinking water (cross-section: 4x1.5 mm2)

  • Single-phase version including switchbox with capacitor, thermal motor protection and On/Off switch

  • Installation and operating instructions

Type key

e.g.

Wilo-Sub TWU 3-0115

TWU

Submersible pump

3

Diameter of the hydraulic unit in inches ["]

01

Nominal volume flow [m3/h]

15

Number of hydraulic stages



Technical data

  • Mains connection: 1~230 V, 50 Hz or 3~400 V, 50 Hz

  • Immersed operating mode: S1

  • Fluid temperature: 3-35 °C

  • Minimum flow rate at motor: 0.08 m/s

  • Max. sand content: 50 g/m3

  • Max. number of starts: 30 /h

  • Max. immersion depth: 150 m

  • Protection class: IP 58

  • Pressure connection: Rp 1



Materials

  • Hydraulic housing: 1.4301 stainless steel

  • Impellers: polycarbonate

  • Hydraulics shaft: 1.4104 stainless steel

  • Motor housing: 1.4301 stainless steel

  • Motor shaft: 1.4305 stainless steel



Description/construction

Submersible-motor pump for vertical or horizontal installation.

Hydraulics

Multistage submersible-motor pump with radial impellers with sectional construction. Integrated non-return valve. All parts in contact with the fluid are made of corrosion-free materials.

Motor

Corrosion-free single-phase or three-phase motor for direct starting, with rewindable motor, oil-filled, self-lubricating bearing.

Cooling

The motor is cooled by the fluid. The motor must always be operated in submerged state. The limit values for the max. fluid temperature and the minimum flow rate must not be exceeded. Vertical installation is possible optionally with or without cooling jacket. Cooling jacket is required for horizontal installation.



Instructions

Technical Specifications

Maximum flow [l/min]
45
Maximum head [m]
45 - 130
Input voltage [V]
230
Power output - P2 [kW]
0.37 - 1.10
Delivery port ["]
1
Pump diameter ["]
3
Maximum immersion depth [m]
60
Drinking water certificate
NO
Float switch
NO
Maximum current [A]
3.20 - 5.85
Maximum liquid temperature [°C]
35
Cable length [m]
1.80
Protection [IP]
58
Automatic thermal protection
YES
Dry run protection
NO
Off switch
YES, NO
Speed ​​control
NO
Capacitor
external, NO
Maximum borehole diameter [mm]
72
Impeller material
noryl
Construction
centrifugal
