WILO Atmos PICO 25/1-8

Thanks to Green Button Technology, simple user interface and standard design, the Wilo-Atmos PICO high-efficiency pump is the ideal entry-level product for single and two-family houses. Equipped with the most essential settings and functions, it can be put into operation for heating, air conditioning and cooling applications extremely quickly and easily. See more

Technical Specifications

Input voltage [V]
230
Power output - P2 [kW]
0,06
Suction port ["]
6/4
Power input - P1 [kW]
4

Show all Tech Specs

in stock 4 pcs

177.36 € VAT included

Delivery accross EU within 3-7 business days %

Brand:
WILO
Category:
Circulator pumps
Product No.:
ZB00073340
Sale group:
CEW01
EAN:
4048482932798
Manuf. No.:
4232696

Product variants

  • Technical Specifications
  • Product No.
  • Input voltage [V]
  • Power output - P2 [kW]
  • Suction port ["]
  • Power input - P1 [kW]
  • Delivery port ["]
  • Drinking water certificate
  • Maximum liquid temperature [°C]
  • Protection [IP]
  • Automatic thermal protection
  • Dry run protection
  • Off switch
  • Speed ​​control
  • Capacitor
  • Impeller material
  • Construction
  • Port-to-port length
  • Availability
  • Price

next

Variant Product No.

Availability

Price (VAT incl.)

WILO Atmos PICO 25/1-4

Product No.: ZB00073338 Sale group: CEW01 EAN: 4048482932712 Manuf. No.: 4232691

in stock
>10 pcs
Product availability
  • central warehouse >10 pcs

128.57 €

Input voltage [V]
230
Power output - P2 [kW]
0,02
Suction port ["]
6/4
Power input - P1 [kW]
4
Delivery port ["]
6/4
Drinking water certificate
YES
Maximum liquid temperature [°C]
95
Protection [IP]
X2D
Dry run protection
NO
Speed ​​control
YES
Impeller material
noryl
Construction
Glandless pumps
Port-to-port length
180

WILO Atmos PICO 25/1-6

Product No.: ZB00073339 Sale group: CEW01 EAN: 4048482932774 Manuf. No.: 4232694

in stock
>10 pcs
Product availability
  • central warehouse >10 pcs

136.71 €

Input voltage [V]
230
Power output - P2 [kW]
0,03
Suction port ["]
6/4
Power input - P1 [kW]
4
Delivery port ["]
6/4
Drinking water certificate
YES
Maximum liquid temperature [°C]
95
Protection [IP]
X2D
Dry run protection
NO
Speed ​​control
YES
Impeller material
noryl
Construction
Glandless pumps
Port-to-port length
180

WILO Atmos PICO 25/1-8

Product No.: ZB00073340 Sale group: CEW01 EAN: 4048482932798 Manuf. No.: 4232696

in stock
4 pcs
Product availability
  • central warehouse 4 pcs

177.36 €

Input voltage [V]
230
Power output - P2 [kW]
0,06
Suction port ["]
6/4
Power input - P1 [kW]
4
Delivery port ["]
6/4
Drinking water certificate
YES
Maximum liquid temperature [°C]
95
Protection [IP]
X2D
Dry run protection
NO
Speed ​​control
YES
Impeller material
noryl
Construction
Glandless pumps
Port-to-port length
180
You are viewing this variant

Product description

Wilo-Atmos PICO – a reliable pump with a 5-year warranty

Are you looking for a pump that will provide you with maximum comfort without complicated settings?
Wilo-Atmos PICO with a 5-year warranty is the ideal solution for any household looking for reliability and energy savings.

Versatile use

  • Whether you heat with radiators, use underfloor heating, or need reliable cooling, one pump can handle it all.
  • Traditional heating systems with radiators
  • Underfloor heating
  • Air conditioning systems

Why will you be satisfied?

  • Easy installation and operation: you don't need to be an expert – the pump has clear LED indicators and a compact design, so you can easily install it even in small spaces.
  • Energy savings of up to 80%: with today's energy prices, every saving counts. Thanks to its smart control, the Wilo-Atmos PICO consumes a minimum of energy – as little as 4 W.
  • Reliability and long service life: no need to worry about breakdowns – the pump has a cast iron housing, a jam-resistant motor, and an automatic jam release function.

Smart features you'll appreciate

  • Variable differential pressure (3 settings)
  • Constant speed (3 levels)
  • Automatic restart after failure
  • LED indicators for quick orientation – green = everything OK

Type code

  • Example: Wilo-Atmos PICO 25/1-6-130
  • Atmos PICO High-efficiency pump (threaded pump), electronically controlled
  • 25/ Nominal connection diameter
  • 1-6 Nominal delivery head range [m]
  • 130 Overall length

Scope of delivery

  • Pump
  • Wilo-Connector
  • Seal
  • Installation and operating instructions

Instructions

Technical Specifications

Input voltage [V]
230
Power output - P2 [kW]
0,06
Suction port ["]
6/4
Power input - P1 [kW]
4
Delivery port ["]
6/4
Drinking water certificate
YES
Maximum liquid temperature [°C]
95
Protection [IP]
X2D
Dry run protection
NO
Speed ​​control
YES
Impeller material
noryl
Construction
Glandless pumps
Port-to-port length
180
