PUMPA inox line MORAVA 5-16-T 400V stainless steel sewage pump for pressure sewers

PUMPA inox line MORAVA 5-16-T 400V stainless steel sewage pump for pressure sewers

All-stainless steel sewage pump for pressure sewers with plastic bypass for installation in lower sumps. The pump excels in considerable simplicity for possible disassembly and cleaning of the pump assembly. See more

Technical Specifications

Maximum flow [l/min]
55
Maximum head [m]
110
Input voltage [V]
3x400
Power output - P2 [kW]
1.10

Show all Tech Specs

from 755.25 VAT included

Choose variant

Delivery accross EU within 2-4 days %

Brand:
PUMPA
Category:
Screw grinder pumps
Product No.:
MAS000074

Product variants

  • Technical Specifications
  • Product No.
  • Maximum flow [l/min]
  • Maximum head [m]
  • Input voltage [V]
  • Power output - P2 [kW]
  • Delivery port ["]
  • Maximum immersion depth [m]
  • Float switch
  • Maximum current [A]
  • Cable length [m]
  • Automatic thermal protection
  • Dry run protection
  • Speed ​​control
  • Capacitor
  • Impeller material
  • Construction
  • Grinder
  • Availability
  • Price

next

Variant Product No.

Availability

Price (VAT incl.)

Pumpa INOX Morava 5-16-T 1,1kW 400V, 10m cable, sewage screw pump with grinder

Product No.: ZB00040415 Sale group: CEPU EAN: 8596455000334 Manuf. No.: SK009510

755.25 €

Maximum flow [l/min]
55
Maximum head [m]
110
Input voltage [V]
3x400
Power output - P2 [kW]
1.10
Delivery port ["]
6/4
Maximum immersion depth [m]
30
Float switch
NO
Maximum current [A]
3.20
Cable length [m]
10
Automatic thermal protection
NO
Dry run protection
NO
Speed ​​control
NO
Capacitor
NO
Impeller material
stainless steel
Construction
submersible
Grinder
YES
Maximum flow [l/min]
55
Maximum head [m]
110
Input voltage [V]
3x400
Power output - P2 [kW]
1.10
Delivery port ["]
6/4
Maximum immersion depth [m]
30
Float switch
NO
Maximum current [A]
3.20
Cable length [m]
15
Automatic thermal protection
NO
Dry run protection
NO
Speed ​​control
NO
Capacitor
NO
Impeller material
stainless steel
Construction
submersible
Grinder
YES

Product description

Description

  • for pressure sewers with plastic bypass for the possibility of installation in lower sumps

Advantages

  • Czech product
  • Large engine bypass clearance
  • Easy handling on a stable base
  • Small size and weight
  • Easy and fast disassembly of the cutting ring and suction body
  • Hardened cutting equipment
  • Voltage 400 V

Technical Specifications

Maximum flow [l/min]
55
Maximum head [m]
110
Input voltage [V]
3x400
Power output - P2 [kW]
1.10
Delivery port ["]
6/4
Maximum immersion depth [m]
30
Float switch
NO
Maximum current [A]
3.20
Cable length [m]
10 - 15
Automatic thermal protection
NO
Dry run protection
NO
Speed ​​control
NO
Capacitor
NO
Impeller material
stainless steel
Construction
submersible
Grinder
YES
