PUMPA inox line DWPM centrifugal pumps 230V

Centrifugal surface pumps with open impeller PUMP INOX LINE DWPM. The hydraulic part of the pumps is made entirely of high-quality AISI304 stainless steel. The pumps are suitable for pumping slightly contaminated liquids that may contain solid particles up to 19 mm in size.   See more

Technical Specifications

Maximum flow [l/min]
100 - 500
Maximum head [m]
10 - 15
Input voltage [V]
230
Power output - P2 [kW]
0.25 - 1.50

Show all Tech Specs

in stock 2 pcs

from 230.14 € VAT included

Choose variant

Delivery accross EU within 3-7 business days %

Brand:
PUMPA
Category:
Horizontal surface pumps
Product No.:
MAS001719

Product variants

  • Technical Specifications
  • Product No.
  • Maximum flow [l/min]
  • Maximum head [m]
  • Input voltage [V]
  • Power output - P2 [kW]
  • Suction port ["]
  • Power input - P1 [kW]
  • Rated flow [l/m]
  • Rated head [m]
  • Delivery port ["]
  • Maximum suction lift [m]
  • Drinking water certificate
  • Maximum current [A]
  • Maximum liquid temperature [°C]
  • Maximum pressure [bar]
  • Maximum particle size [mm]
  • Protection [IP]
  • Automatic thermal protection
  • Dry run protection
  • Off switch
  • Speed ​​control
  • Capacitor
  • Pump design
  • Impeller material
  • Construction
  • Availability
  • Price

next

Variant Product No.

Availability

Price (VAT incl.)

PUMPA INOX LINE DWPM025 0.25kW 230V/50Hz surface pump

Product No.: ZB00075649 Sale group: CESTP EAN: 8596455044857

on demand
check availability
Product availability
  • central warehouse 0 pcs

230.14 €

Check availability

Maximum flow [l/min]
100
Maximum head [m]
10
Input voltage [V]
230
Power output - P2 [kW]
0.25
Suction port ["]
5/4
Power input - P1 [kW]
0.37
Rated flow [l/m]
50
Rated head [m]
8
Delivery port ["]
1
Maximum suction lift [m]
5
Drinking water certificate
NO
Maximum current [A]
1.80
Maximum liquid temperature [°C]
70
Maximum pressure [bar]
3
Maximum particle size [mm]
8
Protection [IP]
55
Automatic thermal protection
YES
Dry run protection
NO
Speed ​​control
NO
Capacitor
integrated
Pump design
horizontal
Impeller material
stainless steel
Construction
centrifugal

PUMPA INOX LINE DWPM50 0.37kW 230V/50Hz surface pump

Product No.: ZB00075653 Sale group: CESTP EAN: 8596455044505

in stock
1 pcs
Product availability
  • central warehouse 1 pcs

243.94 €

Maximum flow [l/min]
110
Maximum head [m]
12
Input voltage [V]
230
Power output - P2 [kW]
0.37
Suction port ["]
5/4
Power input - P1 [kW]
0.55
Rated flow [l/m]
80
Rated head [m]
6.50
Delivery port ["]
1
Maximum suction lift [m]
5
Drinking water certificate
NO
Maximum current [A]
2.50
Maximum liquid temperature [°C]
70
Maximum pressure [bar]
3
Maximum particle size [mm]
8
Protection [IP]
55
Automatic thermal protection
YES
Dry run protection
NO
Off switch
NO
Speed ​​control
NO
Capacitor
integrated
Pump design
horizontal
Impeller material
stainless steel
Construction
centrifugal

PUMPA INOX LINE DWPM100 0.55kW 230V/50Hz surface pump

Product No.: ZB00075655 Sale group: CESTP EAN: 8596455044901

on demand
check availability
Product availability
  • central warehouse 0 pcs

311.16 €

Check availability

Maximum flow [l/min]
300
Maximum head [m]
12
Input voltage [V]
230
Power output - P2 [kW]
0.55
Suction port ["]
6/4
Power input - P1 [kW]
0.75
Rated flow [l/m]
200
Rated head [m]
8
Delivery port ["]
6/4
Maximum suction lift [m]
5
Drinking water certificate
NO
Maximum current [A]
3.50
Maximum liquid temperature [°C]
70
Maximum pressure [bar]
10
Maximum particle size [mm]
10
Protection [IP]
55
Automatic thermal protection
YES
Dry run protection
NO
Off switch
NO
Speed ​​control
NO
Capacitor
integrated
Pump design
horizontal
Impeller material
stainless steel
Construction
centrifugal

PUMPA INOX LINE DWPM150 1.1kW 230V/50Hz surface pump

Product No.: ZB00075663 Sale group: CESTP EAN: 8596455044987

on demand
check availability
Product availability
  • central warehouse 0 pcs

528.92 €

Check availability

Maximum flow [l/min]
415
Maximum head [m]
12
Input voltage [V]
230
Power output - P2 [kW]
1.10
Suction port ["]
2
Power input - P1 [kW]
1.50
Rated flow [l/m]
300
Rated head [m]
7.50
Delivery port ["]
2
Maximum suction lift [m]
5
Drinking water certificate
NO
Maximum current [A]
6.30
Maximum liquid temperature [°C]
70
Maximum pressure [bar]
10
Maximum particle size [mm]
19
Protection [IP]
55
Automatic thermal protection
YES
Dry run protection
NO
Off switch
NO
Speed ​​control
NO
Capacitor
integrated
Pump design
horizontal
Impeller material
stainless steel
Construction
centrifugal

PUMPA INOX LINE DWPM200 1.5kW 230V/50Hz surface pump

Product No.: ZB00075665 Sale group: CESTP EAN: 8596455045007

in stock
1 pcs
Product availability
  • central warehouse 1 pcs

562.50 €

Maximum flow [l/min]
500
Maximum head [m]
15
Input voltage [V]
230
Power output - P2 [kW]
1.50
Suction port ["]
2
Power input - P1 [kW]
1.85
Rated flow [l/m]
300
Rated head [m]
10.50
Delivery port ["]
2
Maximum suction lift [m]
5
Drinking water certificate
NO
Maximum current [A]
8.40
Maximum liquid temperature [°C]
70
Maximum pressure [bar]
10
Maximum particle size [mm]
19
Protection [IP]
55
Automatic thermal protection
YES
Dry run protection
NO
Off switch
NO
Speed ​​control
NO
Capacitor
integrated
Pump design
horizontal
Impeller material
stainless steel
Construction
centrifugal

Product description

Centrifugal surface pumps with open impeller PUMP INOX LINE DWPM. The hydraulic part of the pumps is made entirely of high-quality AISI304 stainless steel. The pumps are suitable for pumping slightly contaminated liquids that may contain solid particles up to 19 mm in size.

Main advantages

  • Safe and reliable operation – the pump is equipped with a mechanical seal
  • Wide range of applications – industrial and domestic applications
  • Corrosion protection – parts coming into contact with the liquid are made of AISI 304 stainless steel
  • Motor: single-phase 1x230V 50Hz

Application

  • Pumping clean and waste water with solid particles up to 19 mm
  • Car washes
  • Industrial washing machines
  • Food applications
  • Swimming pool systems

Solid particle passage

  • DWP025-50: 8 mm
  • DWP100: 10 mm
  • DWP150-400: 19 mm

Instructions

Technical Specifications

Maximum flow [l/min]
100 - 500
Maximum head [m]
10 - 15
Input voltage [V]
230
Power output - P2 [kW]
0.25 - 1.50
Suction port ["]
5/4, 6/4, 2
Power input - P1 [kW]
0.37 - 1.85
Rated flow [l/m]
50 - 300
Rated head [m]
6.50 - 10.50
Delivery port ["]
1, 6/4, 2
Maximum suction lift [m]
5
Drinking water certificate
NO
Maximum current [A]
1.80 - 8.40
Maximum liquid temperature [°C]
70
Maximum pressure [bar]
3 - 10
Maximum particle size [mm]
8 - 19
Protection [IP]
55
Automatic thermal protection
YES
Dry run protection
NO
Off switch
, NO
Speed ​​control
NO
Capacitor
integrated
Pump design
horizontal
Impeller material
stainless steel
Construction
centrifugal
