PUMPA blue line PTM60-1 230V volumetric pump, cable 0,3m

Blue Line PTM60-1 230V displacement pump for pumping clean water. See more

Technical Specifications

Maximum flow [l/min]
35
Maximum head [m]
35
Input voltage [V]
230
Power output - P2 [kW]
0.37

Show all Tech Specs

in stock >100 pcs

50.33 € VAT included

Delivery accross EU within 3-7 business days %

Brand:
PUMPA
Category:
Horizontal surface pumps
Product No.:
ZB00001151
Sale group:
CEBL
EAN:
8596455001690

Product variants

  • Technical Specifications
  • Product No.
  • Maximum flow [l/min]
  • Maximum head [m]
  • Input voltage [V]
  • Power output - P2 [kW]
  • Suction port ["]
  • Delivery port ["]
  • Maximum suction lift [m]
  • Drinking water certificate
  • Maximum current [A]
  • Maximum liquid temperature [°C]
  • Protection [IP]
  • Automatic thermal protection
  • Dry run protection
  • Off switch
  • Speed ​​control
  • Capacitor
  • Pump design
  • Impeller material
  • Construction
  • Availability
  • Price

next

Variant Product No.

Availability

Price (VAT incl.)

PUMPA blue line PTM60-1 230V volumetric pump, cable 0,3m

Product No.: ZB00001151 Sale group: CEBL EAN: 8596455001690

in stock
>100 pcs
Product availability
  • central warehouse >100 pcs

50.33 €

Maximum flow [l/min]
35
Maximum head [m]
35
Input voltage [V]
230
Power output - P2 [kW]
0.37
Suction port ["]
1
Delivery port ["]
1
Maximum suction lift [m]
6
Drinking water certificate
NO
Maximum current [A]
2.50
Maximum liquid temperature [°C]
60
Protection [IP]
44
Automatic thermal protection
YES
Dry run protection
NO
Off switch
NO
Speed ​​control
NO
Capacitor
integrated
Pump design
horizontal
Impeller material
brass
Construction
positive displacement
You are viewing this variant

Product description

Use of the pump PUMPA blue line PTM60-1

  • for pumping clean water

Instructions

Technical Specifications

Maximum flow [l/min]
35
Maximum head [m]
35
Input voltage [V]
230
Power output - P2 [kW]
0.37
Suction port ["]
1
Delivery port ["]
1
Maximum suction lift [m]
6
Drinking water certificate
NO
Maximum current [A]
2.50
Maximum liquid temperature [°C]
60
Protection [IP]
44
Automatic thermal protection
YES
Dry run protection
NO
Off switch
NO
Speed ​​control
NO
Capacitor
integrated
Pump design
horizontal
Impeller material
brass
Construction
positive displacement
