PUMPA blue line PRO PSHD22.2 HT 2,2kW 400V 50Hz, 2" connection, drainage pump for temperatures up to 80°C PUMPA blue line PRO PSHD22.2 HT 2,2kW 400V 50Hz, 2" connection, drainage pump for temperatures up to 80°C PUMPA blue line PRO PSHD22.2 HT 2,2kW 400V 50Hz, 2" connection, drainage pump for temperatures up to 80°C PUMPA blue line PRO PSHD22.2 HT 2,2kW 400V 50Hz, 2" connection, drainage pump for temperatures up to 80°C PUMPA blue line PRO PSHD22.2 HT 2,2kW 400V 50Hz, 2" connection, drainage pump for temperatures up to 80°C

PUMPA blue line PRO PSHD22.2 HT 2,2kW 400V 50Hz, 2" connection, drainage pump for temperatures up to 80°C

High Temperature Submersible Drainage Pump for pumping liquids up to 80°C. Designed for pumping drainage water in the fields of in civil engineering such as mines, quarries, suitable for draining flooded rooms or for pumping out storage tanks, ponds, ponds, sumps or for rainwater collectors. See more

Technical Specifications

Maximum flow [l/min]
550
Maximum head [m]
26
Input voltage [V]
3x400
Power output - P2 [kW]
2,20

Show all Tech Specs

in stock 1 pcs

Goods cannot be purchased online. These are either oversized goods with an individual price of transport or an assortment that can only be purchased on demand. If you are interested in the goods, contact us by email [email protected]

1,022.21 € VAT included

Not sellable online

Delivery accross EU within 3-7 business days %

Brand:
PUMPA
Category:
Wastewater pumps
Product No.:
ZB00072891
Sale group:
CEBLP
EAN:
8596455042310

Product variants

  • Technical Specifications
  • Product No.
  • Maximum flow [l/min]
  • Maximum head [m]
  • Input voltage [V]
  • Power output - P2 [kW]
  • Delivery port ["]
  • Maximum immersion depth [m]
  • Drinking water certificate
  • Float switch
  • Maximum current [A]
  • Maximum liquid temperature [°C]
  • Cable length [m]
  • Maximum particle size [mm]
  • Protection [IP]
  • Automatic thermal protection
  • Dry run protection
  • Off switch
  • Speed ​​control
  • Capacitor
  • Impeller material
  • Construction
  • Grinder
  • Availability
  • Price

next

Variant Product No.

Availability

Price (VAT incl.)

PUMPA blue line PRO PSHD21.5 HT 1,5kW 400V 50Hz, 2" connection, drainage pump for temperatures up to 80°C

Product No.: ZB00072888 Sale group: CEBLP EAN: 8596455042303

in stock
1 pcs
Product availability
  • central warehouse 1 pcs

929.28 €

Not sellable online

Maximum flow [l/min]
433
Maximum head [m]
20.50
Input voltage [V]
3x400
Power output - P2 [kW]
1.50
Delivery port ["]
2
Maximum immersion depth [m]
25
Drinking water certificate
NO
Float switch
NO
Maximum current [A]
3.50
Maximum liquid temperature [°C]
80
Cable length [m]
15
Maximum particle size [mm]
8.50
Protection [IP]
68
Automatic thermal protection
YES
Dry run protection
NO
Off switch
NO
Speed ​​control
NO
Capacitor
NO
Impeller material
cast iron
Construction
submersible
Grinder
NO

PUMPA blue line PRO PSHD22.2 HT 2,2kW 400V 50Hz, 2" connection, drainage pump for temperatures up to 80°C

Product No.: ZB00072891 Sale group: CEBLP EAN: 8596455042310

in stock
1 pcs
Product availability
  • central warehouse 1 pcs

1,022.21 €

Not sellable online

Maximum flow [l/min]
550
Maximum head [m]
26
Input voltage [V]
3x400
Power output - P2 [kW]
2,20
Delivery port ["]
2
Maximum immersion depth [m]
25
Drinking water certificate
NO
Float switch
NO
Maximum current [A]
5
Maximum liquid temperature [°C]
80
Cable length [m]
15
Maximum particle size [mm]
8,50
Protection [IP]
68
Automatic thermal protection
YES
Dry run protection
NO
Off switch
NO
Speed ​​control
NO
Capacitor
NO
Impeller material
cast iron
Construction
submersible
Grinder
NO
You are viewing this variant

PUMPA blue line PRO PSHD23.7 HT 3.7kW 400V 50Hz, 2" connection, drainage pump for temperatures up to 80°C

Product No.: ZB00072892 Sale group: CEBLP EAN: 8596455042327

in stock
1 pcs
Product availability
  • central warehouse 1 pcs

1,537.18 €

Not sellable online

Maximum flow [l/min]
550
Maximum head [m]
31
Input voltage [V]
3x400
Power output - P2 [kW]
3.70
Delivery port ["]
2
Maximum immersion depth [m]
25
Drinking water certificate
NO
Float switch
NO
Maximum current [A]
7.70
Maximum liquid temperature [°C]
80
Cable length [m]
15
Maximum particle size [mm]
8.50
Protection [IP]
68
Automatic thermal protection
YES
Dry run protection
NO
Off switch
NO
Speed ​​control
NO
Capacitor
NO
Impeller material
cast iron
Construction
submersible
Grinder
NO

Product description

Submersible Drainage Pump PUMPA BLUE LINE PSHD HT - High Temperature Submersible Drainage Pump for pumping liquids up to 80°C. Designed for pumping drainage water in the fields of in civil engineering, such as mines, quarries, suitable for drainage of flooded rooms or for pumping out storage tanks, ponds, ponds, sumps or for rainwater collectors.

Main advantages

  • The HT model is improved by the level of insulation, rubber material, bearings and motor lubrication.
  • Motor and pump body made of solid cast iron for long life
  • Significantly increased maximum immersion depth due to mechanical high pressure resistant sealing.
  • Semi-open impeller made of high quality chrome alloy.
  • Efficient engine cooling thanks to a drain channel cast as part of the engine cover.
  • Hermetically sealed built-in motor thermal protection.

Application

  • Drainage of drainage water with abrasives
  • For the construction industry - mines, quarries, buildings
  • Drainage of waste water
  • Other applications

The pump can be rented in our rental shop.

Instructions

Technical Specifications

Maximum flow [l/min]
550
Maximum head [m]
26
Input voltage [V]
3x400
Power output - P2 [kW]
2,20
Delivery port ["]
2
Maximum immersion depth [m]
25
Drinking water certificate
NO
Float switch
NO
Maximum current [A]
5
Maximum liquid temperature [°C]
80
Cable length [m]
15
Maximum particle size [mm]
8,50
Protection [IP]
68
Automatic thermal protection
YES
Dry run protection
NO
Off switch
NO
Speed ​​control
NO
Capacitor
NO
Impeller material
cast iron
Construction
submersible
Grinder
NO
