PUMPA black line BLV 5,5-11 kW sewage pump

PUMPA black line BLV 5,5-11 kW sewage pump

Vortex Slurry Pump with Swirling Impeller. Suitable for pumping wastewater containing coarse impurities up to 100 mm in size. See more

Technical Specifications

Maximum flow [l/min]
1,583 - 3,167
Maximum head [m]
14 - 18
Input voltage [V]
3x400
Power output - P2 [kW]
5.50 - 11

Show all Tech Specs

from 2,154.21 VAT included

Choose variant

Delivery accross EU within 2-4 days %

Brand:
PUMPA
Category:
Sewage pumps
Product No.:
MAS001039

Product variants

  • Technical Specifications
  • Product No.
  • Maximum flow [l/min]
  • Maximum head [m]
  • Input voltage [V]
  • Power output - P2 [kW]
  • Delivery port ["]
  • Maximum immersion depth [m]
  • Float switch
  • Maximum current [A]
  • Cable length [m]
  • Maximum particle size [mm]
  • Protection [IP]
  • Automatic thermal protection
  • Dry run protection
  • Off switch
  • Speed ​​control
  • Capacitor
  • Impeller material
  • Construction
  • Grinder
  • Availability
  • Price

next

Variant Product No.

Availability

Price (VAT incl.)

Maximum flow [l/min]
1 583
Maximum head [m]
15
Input voltage [V]
3x400
Power output - P2 [kW]
5,50
Delivery port ["]
DN80
Maximum immersion depth [m]
20
Float switch
NO
Maximum current [A]
11,70
Cable length [m]
8
Maximum particle size [mm]
80
Protection [IP]
68
Automatic thermal protection
NO
Dry run protection
NO
Off switch
NO
Speed ​​control
NO
Capacitor
NO
Impeller material
cast iron
Construction
submersible
Grinder
NO
Maximum flow [l/min]
1 583
Maximum head [m]
15
Input voltage [V]
3x400
Power output - P2 [kW]
5,50
Delivery port ["]
DN80
Maximum immersion depth [m]
20
Float switch
NO
Maximum current [A]
11,70
Cable length [m]
15
Maximum particle size [mm]
80
Protection [IP]
68
Automatic thermal protection
NO
Dry run protection
NO
Off switch
NO
Speed ​​control
NO
Capacitor
NO
Impeller material
cast iron
Construction
submersible
Grinder
NO
Maximum flow [l/min]
2 250
Maximum head [m]
14
Input voltage [V]
3x400
Power output - P2 [kW]
5,50
Delivery port ["]
DN100
Maximum immersion depth [m]
20
Float switch
NO
Maximum current [A]
11,70
Cable length [m]
8
Maximum particle size [mm]
100
Protection [IP]
68
Automatic thermal protection
NO
Dry run protection
NO
Off switch
NO
Speed ​​control
NO
Capacitor
NO
Impeller material
cast iron
Construction
submersible
Grinder
NO
Maximum flow [l/min]
2 250
Maximum head [m]
14
Input voltage [V]
3x400
Power output - P2 [kW]
5,50
Delivery port ["]
DN100
Maximum immersion depth [m]
20
Float switch
NO
Maximum current [A]
11,70
Cable length [m]
15
Maximum particle size [mm]
100
Protection [IP]
68
Automatic thermal protection
NO
Dry run protection
NO
Off switch
NO
Speed ​​control
NO
Capacitor
NO
Impeller material
cast iron
Construction
submersible
Grinder
NO
Maximum flow [l/min]
1 833
Maximum head [m]
17
Input voltage [V]
3x400
Power output - P2 [kW]
7,50
Delivery port ["]
DN80
Maximum immersion depth [m]
20
Float switch
NO
Maximum current [A]
15,70
Cable length [m]
8
Maximum particle size [mm]
80
Protection [IP]
68
Automatic thermal protection
NO
Dry run protection
NO
Off switch
NO
Speed ​​control
NO
Capacitor
NO
Impeller material
cast iron
Construction
submersible
Grinder
NO
Maximum flow [l/min]
1 833
Maximum head [m]
17
Input voltage [V]
3x400
Power output - P2 [kW]
7,50
Delivery port ["]
DN80
Maximum immersion depth [m]
20
Float switch
NO
Maximum current [A]
15,70
Cable length [m]
15
Maximum particle size [mm]
80
Protection [IP]
68
Automatic thermal protection
NO
Dry run protection
NO
Off switch
NO
Speed ​​control
NO
Capacitor
NO
Impeller material
cast iron
Construction
submersible
Grinder
NO
Maximum flow [l/min]
2 750
Maximum head [m]
15
Input voltage [V]
3x400
Power output - P2 [kW]
7,50
Delivery port ["]
DN100
Maximum immersion depth [m]
20
Float switch
NO
Maximum current [A]
15,70
Cable length [m]
8
Maximum particle size [mm]
100
Protection [IP]
68
Automatic thermal protection
NO
Dry run protection
NO
Off switch
NO
Speed ​​control
NO
Capacitor
NO
Impeller material
cast iron
Construction
submersible
Grinder
NO
Maximum flow [l/min]
2 750
Maximum head [m]
15
Input voltage [V]
3x400
Power output - P2 [kW]
7,50
Delivery port ["]
DN100
Maximum immersion depth [m]
20
Float switch
NO
Maximum current [A]
15,70
Cable length [m]
15
Maximum particle size [mm]
100
Protection [IP]
68
Automatic thermal protection
NO
Dry run protection
NO
Off switch
NO
Speed ​​control
NO
Capacitor
NO
Impeller material
cast iron
Construction
submersible
Grinder
NO
Maximum flow [l/min]
3 167
Maximum head [m]
18
Input voltage [V]
3x400
Power output - P2 [kW]
11
Delivery port ["]
DN100
Maximum immersion depth [m]
20
Float switch
NO
Maximum current [A]
22
Cable length [m]
15
Maximum particle size [mm]
100
Protection [IP]
68
Automatic thermal protection
NO
Dry run protection
NO
Off switch
NO
Speed ​​control
NO
Capacitor
NO
Impeller material
cast iron
Construction
submersible
Grinder
NO

Product description

Description

Vortex Slurry Pump with Swirling Impeller. Suitable for pumping wastewater containing coarse impurities up to 100 mm in size.

Use

  • wastewater pumping
  • gas station
  • wastewater treatment plants
  • drainage water pumping
  • rainwater pumping
  • industrial applications

Technical Specifications

Maximum flow [l/min]
1,583 - 3,167
Maximum head [m]
14 - 18
Input voltage [V]
3x400
Power output - P2 [kW]
5.50 - 11
Delivery port ["]
DN80, DN100
Maximum immersion depth [m]
20
Float switch
NO
Maximum current [A]
11.70 - 22
Cable length [m]
8 - 15
Maximum particle size [mm]
80 - 100
Protection [IP]
68
Automatic thermal protection
NO
Dry run protection
NO
Off switch
NO
Speed ​​control
NO
Capacitor
NO
Impeller material
cast iron
Construction
submersible
Grinder
NO
