GRUNDFOS UNILIFT AP12 submersible wastewater pumps

Grundfos UNILIFT AP12 are stainless-steel submersible pumps designed for pumping non-aggressive water and grey wastewater such as drainage and domestic effluents with particles up to 12 mm. The pump can be used as a portable unit or stationary installation inside and outside buildings See more

Technical Specifications

Maximum flow [l/min]
233.40 - 499.80
Maximum head [m]
10 - 17
Input voltage [V]
230
Power output - P2 [kW]
0.70 - 1.70

Show all Tech Specs

in stock >10 pcs

from 692.89 € VAT included

Choose variant

Delivery accross EU within 3-7 business days %

Brand:
Grundfos
Category:
Wastewater pumps
Product No.:
MAS000504

Product variants

  • Technical Specifications
  • Product No.
  • Maximum flow [l/min]
  • Maximum head [m]
  • Input voltage [V]
  • Power output - P2 [kW]
  • Delivery port ["]
  • Maximum immersion depth [m]
  • Drinking water certificate
  • Float switch
  • Maximum current [A]
  • Cable length [m]
  • Protection [IP]
  • Automatic thermal protection
  • Dry run protection
  • Off switch
  • Speed ​​control
  • Capacitor
  • Impeller material
  • Construction
  • Grinder
  • Availability
  • Price

next

Variant Product No.

Availability

Price (VAT incl.)

Grundfos Unilift AP 12.40.04.A1 230V 0,7kW 10m cable + float switch

Product No.: ZB00002457 Sale group: CEGJ EAN: 5700390901578 Manuf. No.: 96011018

in stock
>10 pcs
Product availability
  • central warehouse >10 pcs

692.89 €

Maximum flow [l/min]
233.40
Maximum head [m]
10
Input voltage [V]
230
Power output - P2 [kW]
0.70
Delivery port ["]
6/4
Maximum immersion depth [m]
10
Float switch
YES
Maximum current [A]
3
Cable length [m]
10
Protection [IP]
68
Automatic thermal protection
YES
Dry run protection
NO
Speed ​​control
NO
Capacitor
integrated
Impeller material
stainless steel
Construction
submersible
Grinder
NO

Grundfos Unilift AP 12.50.11.A1 230V 1,7kW 10m cable + float switch

Product No.: ZB00002465 Sale group: CEGJ EAN: 5700390901332 Manuf. No.: 96010981

in stock
1 pcs
Product availability
  • central warehouse 1 pcs

1,151.73 €

Maximum flow [l/min]
499.80
Maximum head [m]
17
Input voltage [V]
230
Power output - P2 [kW]
1.70
Delivery port ["]
2
Maximum immersion depth [m]
10
Float switch
YES
Maximum current [A]
8.50
Cable length [m]
10
Protection [IP]
68
Automatic thermal protection
YES
Dry run protection
NO
Speed ​​control
NO
Capacitor
integrated
Impeller material
stainless steel
Construction
submersible
Grinder
NO

Product description

Instructions

Technical Specifications

Maximum flow [l/min]
233.40 - 499.80
Maximum head [m]
10 - 17
Input voltage [V]
230
Power output - P2 [kW]
0.70 - 1.70
Delivery port ["]
6/4, 2
Maximum immersion depth [m]
10
Float switch
YES
Maximum current [A]
3 - 8.50
Cable length [m]
10
Protection [IP]
68
Automatic thermal protection
YES
Dry run protection
NO
Speed ​​control
NO
Capacitor
integrated
Impeller material
stainless steel
Construction
submersible
Grinder
NO
