GRUNDFOS MAGNA3 D PN6/10 threaded circulator pump

Double the performance or enjoy reduced downtime in service by having redundancy from the twin pump which operates wirelessly. The intelligence in the MAGNA3 caters for all application needs See more

Technical Specifications

Maximum flow [l/min]
116 - 166
Maximum head [m]
4 - 10
Input voltage [V]
230
Suction port ["]
2

Show all Tech Specs

on demand check availability

from 1,408.37 € VAT included

Choose variant

Delivery accross EU within 2-4 days %

Brand:
Grundfos
Category:
Heating pumps
Product No.:
MAS000481

Product variants

  • Technical Specifications
  • Product No.
  • Maximum flow [l/min]
  • Maximum head [m]
  • Input voltage [V]
  • Suction port ["]
  • Delivery port ["]
  • Maximum current [A]
  • Maximum liquid temperature [°C]
  • Protection [IP]
  • Dry run protection
  • Off switch
  • Speed ​​control
  • Capacitor
  • Impeller material
  • Port-to-port length
  • Availability
  • Price

next

Variant Product No.

Availability

Price (VAT incl.)

Grundfos MAGNA3 D 32-40 180mm 230V PN6/10

Product No.: ZB00030210 Sale group: CEGBB EAN: 5710626495276 Manuf. No.: 97924449

on demand
check availability
Product availability
  • central warehouse 0 pcs

1,408.37 €

Check availability

Maximum flow [l/min]
116
Maximum head [m]
4
Input voltage [V]
230
Suction port ["]
2
Delivery port ["]
2
Maximum current [A]
0.61
Maximum liquid temperature [°C]
110
Protection [IP]
X4
Dry run protection
YES
Off switch
NO
Speed ​​control
YES
Capacitor
integrated
Impeller material
noryl
Port-to-port length
180

Grundfos MAGNA3 D 32-60 180mm 230V PN6/10

Product No.: ZB00030214 Sale group: CEGBB EAN: 5710626495283 Manuf. No.: 97924450

on demand
check availability
Product availability
  • central warehouse 0 pcs

1,645.95 €

Check availability

Maximum flow [l/min]
133
Maximum head [m]
6
Input voltage [V]
230
Suction port ["]
2
Delivery port ["]
2
Maximum current [A]
0.91
Maximum liquid temperature [°C]
110
Protection [IP]
X4
Dry run protection
YES
Off switch
NO
Speed ​​control
YES
Capacitor
integrated
Impeller material
noryl
Port-to-port length
180

Grundfos MAGNA3 D 32-80 180mm 230V PN6/10

Product No.: ZB00030218 Sale group: CEGBB EAN: 5710626495290 Manuf. No.: 97924451

on demand
check availability
Product availability
  • central warehouse 0 pcs

1,717.82 €

Check availability

Maximum flow [l/min]
150
Maximum head [m]
8
Input voltage [V]
230
Suction port ["]
2
Delivery port ["]
2
Maximum current [A]
1.19
Maximum liquid temperature [°C]
110
Protection [IP]
X4
Dry run protection
YES
Off switch
NO
Speed ​​control
YES
Capacitor
integrated
Impeller material
noryl
Port-to-port length
180

Grundfos MAGNA3 D 32-100 180mm 230V PN6/10

Product No.: ZB00030205 Sale group: CEGBB EAN: 5710626495306 Manuf. No.: 97924452

on demand
check availability
Product availability
  • central warehouse 0 pcs

1,866.23 €

Check availability

Maximum flow [l/min]
166
Maximum head [m]
10
Input voltage [V]
230
Suction port ["]
2
Delivery port ["]
2
Maximum current [A]
1,47
Maximum liquid temperature [°C]
110
Protection [IP]
X4
Dry run protection
YES
Off switch
NO
Speed ​​control
YES
Capacitor
integrated
Impeller material
noryl
Port-to-port length
180

Product description

MAGNA3 D is a highly-advanced and intelligent twin circulator pump

The MAGNA3 D canned rotor pump features two pump heads which communicate wirelessly. They can operate in alternating mode, in which one pump operates at a time, cascade mode, in which the second pump head contributes whenever it is necessary, and finally, backup mode, in which one pump is 100 % redundant.

Wirelessly-connected multi-pump functionality

The wireless multi-pump functionality of MAGNA3 D improves reliability and reduces downtime.

The clever solution

Inputs and outputs ensure better system monitoring and optimal pump regulation.

Easy monitoring

A heat energy monitor provides you with an easy overview of the heat energy consumption in the entire system.

No hassel

MAGNA3 D is quick to install and requires no maintenance.

Instructions

Technical Specifications

Maximum flow [l/min]
116 - 166
Maximum head [m]
4 - 10
Input voltage [V]
230
Suction port ["]
2
Delivery port ["]
2
Maximum current [A]
0.61 - 1.47
Maximum liquid temperature [°C]
110
Protection [IP]
X4
Dry run protection
YES
Off switch
NO
Speed ​​control
YES
Capacitor
integrated
Impeller material
noryl
Port-to-port length
180
