GRUNDFOS MAGNA1 N stainless steel circulator pump with flange

previous next
GRUNDFOS MAGNA1 N stainless steel circulator pump with flange

MAGNA1 N is the stainless steel variant for applications where the media requires this (e.g. domestic hot water). With MAGNA1, the job is done in an intuitive and efficient way See more

Technical Specifications

Maximum flow [l/min]
125 - 750
Maximum head [m]
4 - 18
Input voltage [V]
230
Suction port ["]
DN32, DN40, DN50, DN65

Show all Tech Specs

in stock 4 pcs

from 1,059.30 € VAT included

Choose variant

Delivery accross EU within 2-4 days %

Brand:
Grundfos
Category:
Hot water recirculation pumps
Product No.:
MAS000472

Product variants

  • Technical Specifications
  • Product No.
  • Maximum flow [l/min]
  • Maximum head [m]
  • Input voltage [V]
  • Suction port ["]
  • Delivery port ["]
  • Maximum current [A]
  • Maximum liquid temperature [°C]
  • Protection [IP]
  • Dry run protection
  • Off switch
  • Speed ​​control
  • Capacitor
  • Impeller material
  • Port-to-port length
  • Availability
  • Price

next

Variant Product No.

Availability

Price (VAT incl.)

Grundfos MAGNA1 32-40F N 220 230V PN6/10

Product No.: ZB00002375 Sale group: CEGBA EAN: 5712608942389 Manuf. No.: 99221265

on demand
check availability
Product availability
  • central warehouse 0 pcs

1,059.30 €

Check availability

Maximum flow [l/min]
125
Maximum head [m]
4
Input voltage [V]
230
Suction port ["]
DN32
Delivery port ["]
DN32
Maximum current [A]
0.59
Maximum liquid temperature [°C]
110
Protection [IP]
X4
Dry run protection
NO
Off switch
NO
Speed ​​control
YES
Capacitor
integrated
Impeller material
noryl
Port-to-port length
220

Grundfos MAGNA1 32-60F N 220 230V PN6/10

Product No.: ZB00030077 Sale group: CEGBA EAN: 5712608942440 Manuf. No.: 99221271

on demand
check availability
Product availability
  • central warehouse 0 pcs

1,239.65 €

Check availability

Maximum flow [l/min]
150
Maximum head [m]
6
Input voltage [V]
230
Suction port ["]
DN32
Delivery port ["]
DN32
Maximum current [A]
0.90
Maximum liquid temperature [°C]
110
Protection [IP]
X4
Dry run protection
NO
Off switch
NO
Speed ​​control
YES
Capacitor
integrated
Impeller material
noryl
Port-to-port length
220

Grundfos MAGNA1 32-80F N 220 230V PN6/10

Product No.: ZB00002378 Sale group: CEGBA EAN: 5712608942501 Manuf. No.: 99221277

on demand
check availability
Product availability
  • central warehouse 0 pcs

1,304.87 €

Check availability

Maximum flow [l/min]
166.67
Maximum head [m]
8
Input voltage [V]
230
Suction port ["]
DN32
Delivery port ["]
DN32
Maximum current [A]
1.22
Maximum liquid temperature [°C]
110
Protection [IP]
X4
Dry run protection
NO
Off switch
NO
Speed ​​control
YES
Capacitor
integrated
Impeller material
noryl
Port-to-port length
220

Grundfos MAGNA1 32-100F N 220 230V PN6/10

Product No.: ZB00030075 Sale group: CEGBA EAN: 5712608942303 Manuf. No.: 99221257

on demand
check availability
Product availability
  • central warehouse 0 pcs

1,499.87 €

Check availability

Maximum flow [l/min]
166.67
Maximum head [m]
10
Input voltage [V]
230
Suction port ["]
DN32
Delivery port ["]
DN32
Maximum current [A]
1.41
Maximum liquid temperature [°C]
110
Protection [IP]
X4
Dry run protection
NO
Off switch
NO
Speed ​​control
YES
Capacitor
integrated
Impeller material
noryl
Port-to-port length
220

Grundfos MAGNA1 32-120 F N 220 1x230V PN6/10

Product No.: ZB00039808 Sale group: CEGBA EAN: 5712608942624 Manuf. No.: 99221289

in stock
3 pcs
Product availability
  • central warehouse 3 pcs

1,769.88 €

Maximum flow [l/min]
150
Maximum head [m]
12
Input voltage [V]
230
Suction port ["]
DN32
Delivery port ["]
DN32
Maximum current [A]
1.48
Maximum liquid temperature [°C]
110
Protection [IP]
X4
Dry run protection
NO
Off switch
NO
Speed ​​control
YES
Capacitor
integrated
Impeller material
noryl
Port-to-port length
220

Grundfos MAGNA1 40-40F N 220 230V PN6/10

Product No.: ZB00030078 Sale group: CEGBA EAN: 5712608942723 Manuf. No.: 99221299

on demand
check availability
Product availability
  • central warehouse 0 pcs

1,320.97 €

Check availability

Maximum flow [l/min]
200
Maximum head [m]
4
Input voltage [V]
230
Suction port ["]
DN40
Delivery port ["]
DN40
Maximum current [A]
0.72
Maximum liquid temperature [°C]
110
Protection [IP]
X4
Dry run protection
NO
Off switch
NO
Speed ​​control
YES
Capacitor
integrated
Impeller material
noryl
Port-to-port length
220

Grundfos MAGNA1 40-60F N 220 230V PN6/10

Product No.: ZB00002373 Sale group: CEGBA EAN: 5712608942730 Manuf. No.: 99221300

on demand
check availability
Product availability
  • central warehouse 0 pcs

1,451.40 €

Check availability

Maximum flow [l/min]
266.67
Maximum head [m]
6
Input voltage [V]
230
Suction port ["]
DN40
Delivery port ["]
DN40
Maximum current [A]
1.56
Maximum liquid temperature [°C]
110
Protection [IP]
X4
Dry run protection
NO
Off switch
NO
Speed ​​control
YES
Capacitor
integrated
Impeller material
noryl
Port-to-port length
220

Grundfos MAGNA1 40-80FN 220 230V PN6/10

Product No.: ZB00030080 Sale group: CEGBA EAN: 5712608942969 Manuf. No.: 99221323

on demand
check availability
Product availability
  • central warehouse 0 pcs

1,769.96 €

Check availability

Maximum flow [l/min]
300
Maximum head [m]
8
Input voltage [V]
230
Suction port ["]
DN40
Delivery port ["]
DN40
Maximum current [A]
1.18
Maximum liquid temperature [°C]
110
Protection [IP]
X4
Dry run protection
NO
Off switch
NO
Speed ​​control
YES
Capacitor
integrated
Impeller material
noryl
Port-to-port length
220

Grundfos MAGNA1 40-100FN 220 230V PN6/10

Product No.: ZB00014761 Sale group: CEGBA EAN: 5712608942976 Manuf. No.: 99221324

on demand
check availability
Product availability
  • central warehouse 0 pcs

1,950.31 €

Check availability

Maximum flow [l/min]
333.33
Maximum head [m]
10
Input voltage [V]
230
Suction port ["]
DN40
Delivery port ["]
DN40
Maximum current [A]
1.65
Maximum liquid temperature [°C]
110
Protection [IP]
X4
Dry run protection
NO
Off switch
NO
Speed ​​control
YES
Capacitor
integrated
Impeller material
noryl
Port-to-port length
220

Grundfos MAGNA1 40-120FN 250 230V PN6/10

Product No.: ZB00014760 Sale group: CEGBA EAN: 5712608942983 Manuf. No.: 99221325

in stock
1 pcs
Product availability
  • central warehouse 1 pcs

2,168.58 €

Maximum flow [l/min]
366.67
Maximum head [m]
12
Input voltage [V]
230
Suction port ["]
DN40
Delivery port ["]
DN40
Maximum current [A]
2.05
Maximum liquid temperature [°C]
110
Protection [IP]
X4
Dry run protection
NO
Off switch
NO
Speed ​​control
YES
Capacitor
integrated
Impeller material
noryl
Port-to-port length
250

Grundfos MAGNA1 40-150 FN 250 1x230V PN6/10

Product No.: ZB00050252 Sale group: CEGBA EAN: 5712608942990 Manuf. No.: 99221326

on demand
check availability
Product availability
  • central warehouse 0 pcs

2,646.41 €

Check availability

Maximum flow [l/min]
400
Maximum head [m]
15
Input voltage [V]
230
Suction port ["]
DN40
Delivery port ["]
DN40
Maximum current [A]
2.71
Maximum liquid temperature [°C]
110
Protection [IP]
X4
Dry run protection
NO
Off switch
NO
Speed ​​control
YES
Capacitor
integrated
Impeller material
noryl
Port-to-port length
250

Grundfos MAGNA1 50-60F N 240 230V PN6/10

Product No.: ZB00002408 Sale group: CEGBA EAN: 5712608943300 Manuf. No.: 99221358

on demand
check availability
Product availability
  • central warehouse 0 pcs

2,299.78 €

Check availability

Maximum flow [l/min]
400
Maximum head [m]
6
Input voltage [V]
230
Suction port ["]
DN50
Delivery port ["]
DN50
Maximum current [A]
1.15
Maximum liquid temperature [°C]
110
Protection [IP]
X4
Dry run protection
NO
Off switch
NO
Speed ​​control
YES
Capacitor
integrated
Impeller material
noryl
Port-to-port length
240

Grundfos MAGNA1 50-80 F N 240 1x230V PN6/10

Product No.: ZB00042322 Sale group: CEGBA EAN: 5712608943317 Manuf. No.: 99221359

on demand
check availability
Product availability
  • central warehouse 0 pcs

2,530.70 €

Check availability

Maximum flow [l/min]
433.33
Maximum head [m]
8
Input voltage [V]
230
Suction port ["]
DN50
Delivery port ["]
DN50
Maximum current [A]
1.48
Maximum liquid temperature [°C]
110
Protection [IP]
X4
Dry run protection
NO
Off switch
NO
Speed ​​control
YES
Capacitor
integrated
Impeller material
noryl
Port-to-port length
240

Grundfos MAGNA1 50-100 F N 280 1x230V PN6/10

Product No.: ZB00044657 Sale group: CEGBA EAN: 5712608943324 Manuf. No.: 99221360

on demand
check availability
Product availability
  • central warehouse 0 pcs

2,679.81 €

Check availability

Maximum flow [l/min]
466.67
Maximum head [m]
10
Input voltage [V]
230
Suction port ["]
DN50
Delivery port ["]
DN50
Maximum current [A]
1.90
Maximum liquid temperature [°C]
110
Protection [IP]
X4
Dry run protection
NO
Off switch
NO
Speed ​​control
YES
Capacitor
integrated
Impeller material
noryl
Port-to-port length
280

Grundfos MAGNA1 50-120 F N 280 1x230V PN6/10

Product No.: ZB00044315 Sale group: CEGBA EAN: 5712608943331 Manuf. No.: 99221361

on demand
check availability
Product availability
  • central warehouse 0 pcs

2,827.55 €

Check availability

Maximum flow [l/min]
500
Maximum head [m]
12
Input voltage [V]
230
Suction port ["]
DN50
Delivery port ["]
DN50
Maximum current [A]
2.37
Maximum liquid temperature [°C]
110
Protection [IP]
X4
Dry run protection
NO
Off switch
NO
Speed ​​control
YES
Capacitor
integrated
Impeller material
noryl
Port-to-port length
280

Grundfos MAGNA1 50-180 F N 280 1x230V PN6/10

Product No.: ZB00048415 Sale group: CEGBA EAN: 5712608943355 Manuf. No.: 99221363

on demand
check availability
Product availability
  • central warehouse 0 pcs

3,821.20 €

Check availability

Maximum flow [l/min]
583.33
Maximum head [m]
18
Input voltage [V]
230
Suction port ["]
DN50
Delivery port ["]
DN50
Maximum current [A]
3.40
Maximum liquid temperature [°C]
110
Protection [IP]
X4
Dry run protection
NO
Off switch
NO
Speed ​​control
YES
Capacitor
integrated
Impeller material
noryl
Port-to-port length
280

Grundfos MAGNA1 65-60FN 340mm 230V PN6/10

Product No.: ZB00040891 Sale group: CEGBA EAN: 5712608943676 Manuf. No.: 99221395

on demand
check availability
Product availability
  • central warehouse 0 pcs

2,797.12 €

Check availability

Maximum flow [l/min]
583.33
Maximum head [m]
6
Input voltage [V]
230
Suction port ["]
DN65
Delivery port ["]
DN65
Maximum current [A]
1.64
Maximum liquid temperature [°C]
110
Protection [IP]
X4
Dry run protection
NO
Off switch
NO
Speed ​​control
YES
Capacitor
integrated
Impeller material
noryl
Port-to-port length
340

Grundfos MAGNA1 65-80 F N 340 1x230V PN6/10

Product No.: ZB00050256 Sale group: CEGBA EAN: 5712608943683 Manuf. No.: 99221396

on demand
check availability
Product availability
  • central warehouse 0 pcs

3,044.07 €

Check availability

Maximum flow [l/min]
583.33
Maximum head [m]
8
Input voltage [V]
230
Suction port ["]
DN65
Delivery port ["]
DN65
Maximum current [A]
2.11
Maximum liquid temperature [°C]
110
Protection [IP]
X4
Dry run protection
NO
Off switch
NO
Speed ​​control
YES
Capacitor
integrated
Impeller material
noryl
Port-to-port length
340

Grundfos MAGNA1 65-100 F N 230V PN6/10

Product No.: ZB00044724 Sale group: CEGBA EAN: 5712608943690 Manuf. No.: 99221397

on demand
check availability
Product availability
  • central warehouse 0 pcs

3,207.79 €

Check availability

Maximum flow [l/min]
666.67
Maximum head [m]
10
Input voltage [V]
230
Suction port ["]
DN65
Delivery port ["]
DN65
Maximum current [A]
2.73
Maximum liquid temperature [°C]
110
Protection [IP]
X4
Dry run protection
NO
Off switch
NO
Speed ​​control
YES
Capacitor
integrated
Impeller material
noryl
Port-to-port length
340

Grundfos MAGNA1 65-120 F N 340 1x230V PN6/10

Product No.: ZB00044314 Sale group: CEGBA EAN: 5712608943706 Manuf. No.: 99221398

on demand
check availability
Product availability
  • central warehouse 0 pcs

3,439.38 €

Check availability

Maximum flow [l/min]
750
Maximum head [m]
12
Input voltage [V]
230
Suction port ["]
DN65
Delivery port ["]
DN65
Maximum current [A]
3.42
Maximum liquid temperature [°C]
110
Protection [IP]
X4
Dry run protection
NO
Off switch
NO
Speed ​​control
YES
Capacitor
integrated
Impeller material
noryl
Port-to-port length
340

Product description

Instructions

Technical Specifications

Maximum flow [l/min]
125 - 750
Maximum head [m]
4 - 18
Input voltage [V]
230
Suction port ["]
DN32, DN40, DN50, DN65
Delivery port ["]
DN32, DN40, DN50, DN65
Maximum current [A]
0.59 - 3.42
Maximum liquid temperature [°C]
110
Protection [IP]
X4
Dry run protection
NO
Off switch
NO
Speed ​​control
YES
Capacitor
integrated
Impeller material
noryl
Port-to-port length
220, 250, 240, 280, 340
