GRUNDFOS ALPHA2 circulator pumps

Grundfos ALPHA2 pumps are high-efficiency circulators, designed for heating and air-conditioning systems. The pump features AUTOADAPT which automatically adjusts the pump to system demands for optimal comfort and the lowest energy consumption as well as simple commissioning See more

Technical Specifications

Maximum flow [l/min]
40 - 63
Maximum head [m]
4 - 7.40
Input voltage [V]
230
Suction port ["]
1, 6/4, 2, 5/4

Show all Tech Specs

in stock >100 pcs

from 274.97 € VAT included

Choose variant

Delivery accross EU within 2-4 days %

Brand:
Grundfos
Category:
Heating pumps
Product No.:
MAS000466

Product variants

  • Technical Specifications
  • Product No.
  • Maximum flow [l/min]
  • Maximum head [m]
  • Input voltage [V]
  • Suction port ["]
  • Power input - P1 [kW]
  • Delivery port ["]
  • Maximum current [A]
  • Maximum liquid temperature [°C]
  • Protection [IP]
  • Dry run protection
  • Off switch
  • Speed ​​control
  • Capacitor
  • Impeller material
  • Construction
  • Port-to-port length
  • Availability
  • Price

next

Variant Product No.

Availability

Price (VAT incl.)

Grundfos ALPHA2 15-40 230V PN10 130mm

Product No.: ZB00002244 Sale group: CEGDD EAN: 5713828674074 Manuf. No.: 99411107

in stock
6 pcs
Product availability
  • central warehouse 6 pcs

302.25 €

Maximum flow [l/min]
40
Maximum head [m]
4
Input voltage [V]
230
Suction port ["]
1
Power input - P1 [kW]
0.02
Delivery port ["]
1
Maximum current [A]
0.18
Maximum liquid temperature [°C]
110
Protection [IP]
X4
Dry run protection
NO
Off switch
NO
Speed ​​control
YES
Capacitor
integrated
Impeller material
noryl
Port-to-port length
130

Grundfos ALPHA2 15-60 230V PN10 130mm

Product No.: ZB00002245 Sale group: CEGDD EAN: 5713828674180 Manuf. No.: 99411114

in stock
3 pcs
Product availability
  • central warehouse 3 pcs

347.50 €

Maximum flow [l/min]
40
Maximum head [m]
6
Input voltage [V]
230
Suction port ["]
1
Power input - P1 [kW]
0.03
Delivery port ["]
1
Maximum current [A]
0.32
Maximum liquid temperature [°C]
110
Protection [IP]
X4
Dry run protection
NO
Off switch
NO
Speed ​​control
YES
Capacitor
integrated
Impeller material
noryl
Port-to-port length
130

Grundfos ALPHA2 25-40 230V PN10 130mm

Product No.: ZB00002246 Sale group: CEGDD EAN: 5713828674753 Manuf. No.: 99411143

in stock
5 pcs
Product availability
  • central warehouse 5 pcs

274.97 €

Maximum flow [l/min]
40
Maximum head [m]
4
Input voltage [V]
230
Suction port ["]
6/4
Power input - P1 [kW]
0.02
Delivery port ["]
6/4
Maximum current [A]
0.18
Maximum liquid temperature [°C]
110
Protection [IP]
X4
Dry run protection
NO
Off switch
NO
Speed ​​control
YES
Capacitor
integrated
Impeller material
noryl
Port-to-port length
130

Grundfos ALPHA2 25-60 230V PN10 130mm

Product No.: ZB00002250 Sale group: CEGDD EAN: 5713828674821 Manuf. No.: 99411150

in stock
5 pcs
Product availability
  • central warehouse 5 pcs

316.23 €

Maximum flow [l/min]
40
Maximum head [m]
6
Input voltage [V]
230
Suction port ["]
6/4
Power input - P1 [kW]
0.03
Delivery port ["]
6/4
Maximum current [A]
0.32
Maximum liquid temperature [°C]
110
Protection [IP]
X4
Dry run protection
NO
Off switch
NO
Speed ​​control
YES
Capacitor
integrated
Impeller material
noryl
Port-to-port length
130

Grundfos ALPHA2 25-40 230V PN10 180mm

Product No.: ZB00002247 Sale group: CEGDD EAN: 5713828674906 Manuf. No.: 99411165

in stock
>100 pcs
Product availability
  • central warehouse >100 pcs

274.98 €

Maximum flow [l/min]
40
Maximum head [m]
4
Input voltage [V]
230
Suction port ["]
6/4
Power input - P1 [kW]
0.02
Delivery port ["]
6/4
Maximum current [A]
0.18
Maximum liquid temperature [°C]
110
Protection [IP]
X4
Dry run protection
NO
Off switch
NO
Speed ​​control
YES
Capacitor
integrated
Impeller material
noryl
Port-to-port length
180

Grundfos ALPHA2 25-60 230V PN10 180mm

Product No.: ZB00002251 Sale group: CEGDD EAN: 5713828675248 Manuf. No.: 99411175

in stock
>100 pcs
Product availability
  • central warehouse >100 pcs

316.24 €

Maximum flow [l/min]
40
Maximum head [m]
6
Input voltage [V]
230
Suction port ["]
6/4
Power input - P1 [kW]
0.03
Delivery port ["]
6/4
Maximum current [A]
0.32
Maximum liquid temperature [°C]
110
Protection [IP]
X4
Dry run protection
NO
Off switch
NO
Speed ​​control
YES
Capacitor
integrated
Impeller material
noryl
Port-to-port length
180

Grundfos ALPHA2 25-80 230V PN10 180mm

Product No.: ZB00002413 Sale group: CEGDD EAN: 5713828675293 Manuf. No.: 99411178

in stock
>10 pcs
Product availability
  • central warehouse >10 pcs

393.44 €

Maximum flow [l/min]
63
Maximum head [m]
7.40
Input voltage [V]
230
Suction port ["]
1
Power input - P1 [kW]
0.05
Delivery port ["]
1
Protection [IP]
X4D
Dry run protection
YES
Off switch
NO
Speed ​​control
YES
Capacitor
NO
Impeller material
noryl
Construction
Glandless pumps
Port-to-port length
180

Grundfos ALPHA2 32-40 230V PN10 180mm

Product No.: ZB00002254 Sale group: CEGDD EAN: 5713828675712 Manuf. No.: 99411207

in stock
3 pcs
Product availability
  • central warehouse 3 pcs

302.28 €

Maximum flow [l/min]
40
Maximum head [m]
4
Input voltage [V]
230
Suction port ["]
2
Power input - P1 [kW]
0.02
Delivery port ["]
2
Maximum current [A]
0.18
Maximum liquid temperature [°C]
110
Protection [IP]
X4
Dry run protection
NO
Off switch
NO
Speed ​​control
YES
Capacitor
integrated
Impeller material
noryl
Port-to-port length
180

Grundfos ALPHA2 32-60 230V PN10 180mm

Product No.: ZB00002255 Sale group: CEGDD EAN: 5713828675972 Manuf. No.: 99411221

in stock
9 pcs
Product availability
  • central warehouse 9 pcs

347.53 €

Maximum flow [l/min]
40
Maximum head [m]
6
Input voltage [V]
230
Suction port ["]
2
Power input - P1 [kW]
0.03
Delivery port ["]
2
Maximum current [A]
0.32
Maximum liquid temperature [°C]
110
Protection [IP]
X4
Dry run protection
NO
Off switch
NO
Speed ​​control
YES
Capacitor
integrated
Impeller material
noryl
Port-to-port length
180

Grundfos ALPHA2 32-80 230V PN10 180mm

Product No.: ZB00002414 Sale group: CEGDD EAN: 5713828676894 Manuf. No.: 99411263

in stock
>10 pcs
Product availability
  • central warehouse >10 pcs

434.71 €

Maximum flow [l/min]
63
Maximum head [m]
7.40
Input voltage [V]
230
Suction port ["]
5/4
Power input - P1 [kW]
0.05
Delivery port ["]
5/4
Protection [IP]
X4D
Dry run protection
YES
Off switch
NO
Speed ​​control
YES
Capacitor
NO
Impeller material
noryl
Construction
Glandless pumps
Port-to-port length
180

Grundfos ALPHA2 25-80 N 230V PN10 180mm

Product No.: ZB00002415 Sale group: CEGDF EAN: 5713828680198 Manuf. No.: 99411428

in stock
2 pcs
Product availability
  • central warehouse 2 pcs

803.82 €

Maximum flow [l/min]
63
Maximum head [m]
7.40
Input voltage [V]
230
Suction port ["]
1
Power input - P1 [kW]
0.05
Delivery port ["]
1
Protection [IP]
X4D
Dry run protection
YES
Off switch
NO
Speed ​​control
YES
Capacitor
NO
Impeller material
noryl
Construction
Glandless pumps
Port-to-port length
180

Grundfos ALPHA2 25-40 N 230V PN10 180mm

Product No.: ZB00002249 Sale group: CEGDF EAN: 5713828678720 Manuf. No.: 99411365

in stock
5 pcs
Product availability
  • central warehouse 5 pcs

562.06 €

Maximum flow [l/min]
40
Maximum head [m]
4
Input voltage [V]
230
Suction port ["]
6/4
Power input - P1 [kW]
0.02
Delivery port ["]
6/4
Maximum current [A]
0.18
Maximum liquid temperature [°C]
110
Protection [IP]
X4
Dry run protection
NO
Off switch
NO
Speed ​​control
YES
Capacitor
integrated
Impeller material
noryl
Port-to-port length
180

Grundfos ALPHA2 32-80 N 230V PN10 180mm

Product No.: ZB00029163 Sale group: CEGDF EAN: 5713828680358 Manuf. No.: 99411449

in stock
2 pcs
Product availability
  • central warehouse 2 pcs

978.07 €

Maximum flow [l/min]
63
Maximum head [m]
7.40
Input voltage [V]
230
Suction port ["]
5/4
Power input - P1 [kW]
0.05
Delivery port ["]
5/4
Protection [IP]
X4D
Dry run protection
YES
Off switch
NO
Speed ​​control
YES
Capacitor
NO
Impeller material
noryl
Construction
Glandless pumps
Port-to-port length
180

Grundfos ALPHA2 25-60 N 230V PN10 180mm

Product No.: ZB00002253 Sale group: CEGDF EAN: 5713828679895 Manuf. No.: 99411424

in stock
2 pcs
Product availability
  • central warehouse 2 pcs

646.28 €

Maximum flow [l/min]
40
Maximum head [m]
6
Input voltage [V]
230
Suction port ["]
6/4
Power input - P1 [kW]
0.03
Delivery port ["]
6/4
Maximum current [A]
0.32
Maximum liquid temperature [°C]
110
Protection [IP]
X4
Dry run protection
NO
Off switch
NO
Speed ​​control
YES
Capacitor
integrated
Impeller material
noryl
Port-to-port length
180

Product description

Instructions

Technical Specifications

Maximum flow [l/min]
40 - 63
Maximum head [m]
4 - 7.40
Input voltage [V]
230
Suction port ["]
1, 6/4, 2, 5/4
Power input - P1 [kW]
0.02 - 0.05
Delivery port ["]
1, 6/4, 2, 5/4
Maximum current [A]
0.18 - 0.32
Maximum liquid temperature [°C]
110
Protection [IP]
X4, X4D
Dry run protection
NO, YES
Off switch
NO
Speed ​​control
YES
Capacitor
integrated, NO
Impeller material
noryl
Construction
Glandless pumps
Port-to-port length
130, 180
