GRUNDFOS ALPHA SOLAR circulator pumps

Grundfos ALPHA SOLAR pumps are high-efficiency circulators, designed for thermal solar systems. The pump features three constant-curve modes. The speed can also be controlled by a low-voltage PWM signal from a solar controller to optimise the solar harvesting and temperature of the system See more

Technical Specifications

Maximum head [m]
7.50 - 14.50
Input voltage [V]
230
Suction port ["]
6/4, 1
Delivery port ["]
6/4, 1

Show all Tech Specs

in stock 2 pcs

from 353.38 € VAT included

Choose variant

Delivery accross EU within 3-7 business days %

Brand:
Grundfos
Category:
Circulator pumps for domestic use
Product No.:
MAS000486

Product variants

  • Technical Specifications
  • Product No.
  • Maximum head [m]
  • Input voltage [V]
  • Suction port ["]
  • Delivery port ["]
  • Drinking water certificate
  • Maximum current [A]
  • Maximum liquid temperature [°C]
  • Protection [IP]
  • Automatic thermal protection
  • Dry run protection
  • Off switch
  • Speed ​​control
  • Capacitor
  • Impeller material
  • Construction
  • Port-to-port length
  • Availability
  • Price

next

Variant Product No.

Availability

Price (VAT incl.)

Grundfos ALPHA Solar 25-145 230V PN10 180mm

Product No.: ZB00039806 Sale group: CEGDD EAN: 5712604776643 Manuf. No.: 98989297

on demand
check availability
Product availability
  • central warehouse 0 pcs

393.31 €

Check availability

Maximum head [m]
14.50
Input voltage [V]
230
Suction port ["]
6/4
Delivery port ["]
6/4
Maximum current [A]
0.58
Maximum liquid temperature [°C]
110
Protection [IP]
X4
Dry run protection
NO
Off switch
NO
Speed ​​control
YES
Capacitor
integrated
Impeller material
noryl
Port-to-port length
180

Grundfos ALPHA Solar 25-75 230V PN10 180mm

Product No.: ZB00040592 Sale group: CEGDD EAN: 5712604776674 Manuf. No.: 98989300

on demand
check availability
Product availability
  • central warehouse 0 pcs

366.69 €

Check availability

Maximum head [m]
7.50
Input voltage [V]
230
Suction port ["]
6/4
Delivery port ["]
6/4
Maximum current [A]
0.52
Maximum liquid temperature [°C]
110
Protection [IP]
X4
Dry run protection
NO
Off switch
NO
Speed ​​control
YES
Capacitor
integrated
Impeller material
noryl
Port-to-port length
180

Grundfos ALPHA Solar 25-75 230V PN10 130mm

Product No.: ZB00040966 Sale group: CEGDD EAN: 5712604776667 Manuf. No.: 98989299

on demand
check availability
Product availability
  • central warehouse 0 pcs

366.69 €

Check availability

Maximum head [m]
7.50
Input voltage [V]
230
Suction port ["]
6/4
Delivery port ["]
6/4
Maximum current [A]
0.48
Maximum liquid temperature [°C]
110
Protection [IP]
X4
Dry run protection
NO
Off switch
NO
Speed ​​control
YES
Capacitor
integrated
Impeller material
noryl
Port-to-port length
130

Grundfos ALPHA Solar 15-75 230V PN10 130mm

Product No.: ZB00048843 Sale group: CEGDD EAN: 5712604776650 Manuf. No.: 98989298

in stock
2 pcs
Product availability
  • central warehouse 2 pcs

353.38 €

Maximum head [m]
7.50
Input voltage [V]
230
Suction port ["]
1
Delivery port ["]
1
Maximum current [A]
0.48
Maximum liquid temperature [°C]
110
Protection [IP]
X4
Dry run protection
NO
Off switch
NO
Speed ​​control
YES
Capacitor
integrated
Impeller material
noryl
Port-to-port length
130

Product description

Instructions

Technical Specifications

Maximum head [m]
7.50 - 14.50
Input voltage [V]
230
Suction port ["]
6/4, 1
Delivery port ["]
6/4, 1
Maximum current [A]
0.48 - 0.58
Maximum liquid temperature [°C]
110
Protection [IP]
X4
Dry run protection
NO
Off switch
NO
Speed ​​control
YES
Capacitor
integrated
Impeller material
noryl
Port-to-port length
180, 130
