Franklin Electric 4 VS 15 submersible pumps with Franklin Electric 230V motor

  • Franklin Electric 4 VS 15 submersible pumps with Franklin Electric 230V motor
    Franklin Electric 4 VS 15 submersible pumps with Franklin Electric 230V motor
  • Franklin Electric 4 VS 15 submersible pumps with Franklin Electric 230V motor
    Franklin Electric 4 VS 15 submersible pumps with Franklin Electric 230V motor
  • Franklin Electric 4 VS 15 submersible pumps with Franklin Electric 230V motor
    Franklin Electric 4 VS 15 submersible pumps with Franklin Electric 230V motor

Drinking water certificate Stainless steel

previous next
Franklin Electric 4 VS 15 submersible pumps with Franklin Electric 230V motor Franklin Electric 4 VS 15 submersible pumps with Franklin Electric 230V motor Franklin Electric 4 VS 15 submersible pumps with Franklin Electric 230V motor
Franklin Electric 4 VS 15 submersible pumps with Franklin Electric 230V motor

4 "submersible pumps are characterized by proven components that are able to withstand the harshest environments and provide excellent performance for irrigation, water systems, water transfer systems, recirculation. See more

Technical Specifications

Maximum flow [l/min]
400
Maximum head [m]
46
Input voltage [V]
230
Power output - P2 [kW]
2.20

Show all Tech Specs

on demand check availability

936.76 € VAT included

Choose variant

Delivery accross EU within 3-7 business days %

Brand:
Franklin Electric
Category:
Submersible borehole pumps
Product No.:
MAS001501

Product variants

  • Technical Specifications
  • Product No.
  • Maximum flow [l/min]
  • Maximum head [m]
  • Input voltage [V]
  • Power output - P2 [kW]
  • Rated flow [l/m]
  • Rated head [m]
  • Delivery port ["]
  • Pump diameter ["]
  • Maximum immersion depth [m]
  • Drinking water certificate
  • Float switch
  • Maximum current [A]
  • Maximum liquid temperature [°C]
  • Cable length [m]
  • Maximum particle size [mm]
  • Protection [IP]
  • Automatic thermal protection
  • Dry run protection
  • Off switch
  • Speed ​​control
  • Capacitor
  • Maximum borehole diameter [mm]
  • Impeller material
  • Construction
  • Availability
  • Price

next

Variant Product No.

Availability

Price (VAT incl.)

Franklin Electric 4 VS 15/08 2,2kW, 70uF, 230V submersible pump with Franklin Electric motor

Product No.: ZB00067544 Sale group: CEFR EAN: 8596455037651

on demand
check availability
Product availability
  • central warehouse 0 pcs

936.76 €

Check availability

Maximum flow [l/min]
400
Maximum head [m]
46
Input voltage [V]
230
Power output - P2 [kW]
2.20
Rated flow [l/m]
250
Rated head [m]
26
Delivery port ["]
2
Pump diameter ["]
4
Maximum immersion depth [m]
150
Drinking water certificate
YES
Float switch
NO
Maximum current [A]
14
Maximum liquid temperature [°C]
30
Cable length [m]
1.50
Maximum particle size [mm]
2
Protection [IP]
68
Automatic thermal protection
NO
Dry run protection
NO
Off switch
NO
Speed ​​control
NO
Capacitor
external
Maximum borehole diameter [mm]
95
Impeller material
noryl
Construction
centrifugal
this variant suits your choice

Product description

APPLICATIONS

  • Municipal water works, fountains and waste water
  • Water distribution and pressure boosting
  • Irrigation and sprinkler systems, water treatment plants, filtration and reverse osmosis
  • Industrial cooling and processing
  • Mining industry, drainage and dewatering
  • Fire-fighting equipment
  • Water supply to and from tanks, reservoir and wells
  • Lifting and distribution of a wide range of liquids
  • Autoclave and cistern charge and discharge
  • Turf and landscape
  • Greenhouses and nurseries
  • Residential and farm wells and drainage
  • Food industry
  • General industry


FEATURES

  • Compact, reliable and suited to operate in horizontal position.
  • Built-in check valve to protect the pump against water hammer risk.
  • Floating impellers to grant a better performance and longer life for the pump against abrasion.
  • The hydraulic design is such to enhance the overall efficiency thus reducing energy consumption and making the pumping systems more cost effective.

Instructions

Technical Specifications

Maximum flow [l/min]
400
Maximum head [m]
46
Input voltage [V]
230
Power output - P2 [kW]
2.20
Rated flow [l/m]
250
Rated head [m]
26
Delivery port ["]
2
Pump diameter ["]
4
Maximum immersion depth [m]
150
Drinking water certificate
YES
Float switch
NO
Maximum current [A]
14
Maximum liquid temperature [°C]
30
Cable length [m]
1.50
Maximum particle size [mm]
2
Protection [IP]
68
Automatic thermal protection
NO
Dry run protection
NO
Off switch
NO
Speed ​​control
NO
Capacitor
external
Maximum borehole diameter [mm]
95
Impeller material
noryl
Construction
centrifugal

Product Safety Information

Company responsible for product safety:
Franklin Electric S.r.l.
Via Asolo, 7, 36031 Dueville - Vicenza, IT
e-mail: [email protected]
