Franklin Electric 4 VS 1 submersible pumps with Franklin Electric 400V motor

  • Franklin Electric 4 VS 1 submersible pumps with Franklin Electric 400V motor
    Franklin Electric 4 VS 1 submersible pumps with Franklin Electric 400V motor
  • Franklin Electric 4 VS 1 submersible pumps with Franklin Electric 400V motor
    Franklin Electric 4 VS 1 submersible pumps with Franklin Electric 400V motor
  • Franklin Electric 4 VS 1 submersible pumps with Franklin Electric 400V motor
    Franklin Electric 4 VS 1 submersible pumps with Franklin Electric 400V motor

Drinking water certificate

previous next
Franklin Electric 4 VS 1 submersible pumps with Franklin Electric 400V motor Franklin Electric 4 VS 1 submersible pumps with Franklin Electric 400V motor Franklin Electric 4 VS 1 submersible pumps with Franklin Electric 400V motor
Franklin Electric 4 VS 1 submersible pumps with Franklin Electric 400V motor

4 "submersible pumps are characterized by proven components that are able to withstand the harshest environments and provide excellent performance for irrigation, water systems, water transfer systems, recirculation. See more

Technical Specifications

Maximum flow [l/min]
25
Maximum head [m]
68 - 241
Input voltage [V]
3x400
Power output - P2 [kW]
0.37 - 1.10

Show all Tech Specs

in stock 1 pcs

from 534.82 € VAT included

Choose variant

Delivery accross EU within 3-7 business days %

Brand:
Franklin Electric
Category:
Submersible borehole pumps
Product No.:
MAS001478

Product variants

  • Technical Specifications
  • Product No.
  • Maximum flow [l/min]
  • Maximum head [m]
  • Input voltage [V]
  • Power output - P2 [kW]
  • Rated flow [l/m]
  • Rated head [m]
  • Delivery port ["]
  • Pump diameter ["]
  • Maximum immersion depth [m]
  • Drinking water certificate
  • Float switch
  • Maximum current [A]
  • Maximum liquid temperature [°C]
  • Cable length [m]
  • Maximum particle size [mm]
  • Protection [IP]
  • Automatic thermal protection
  • Dry run protection
  • Off switch
  • Speed ​​control
  • Maximum borehole diameter [mm]
  • Impeller material
  • Construction
  • Availability
  • Price

next

Variant Product No.

Availability

Price (VAT incl.)

Franklin Electric 4 VS 1/10 0.37kW 400V submersible pump with motor FK

Product No.: ZB00067556 Sale group: CEFR EAN: 8596455037774

in stock
1 pcs
Product availability
  • central warehouse 1 pcs
  • available within 5 working days 2 pcs

534.82 €

Maximum flow [l/min]
25
Maximum head [m]
68
Input voltage [V]
3x400
Power output - P2 [kW]
0.37
Rated flow [l/m]
15
Rated head [m]
45
Delivery port ["]
5/4
Pump diameter ["]
4
Maximum immersion depth [m]
150
Drinking water certificate
YES
Float switch
NO
Maximum current [A]
1.10
Maximum liquid temperature [°C]
30
Cable length [m]
1.50
Maximum particle size [mm]
2
Protection [IP]
68
Automatic thermal protection
NO
Dry run protection
NO
Off switch
NO
Speed ​​control
NO
Maximum borehole diameter [mm]
95
Impeller material
noryl
Construction
centrifugal
this variant suits your choice

Franklin Electric 4 VS 1/13 0.37kW 400V submersible pump with Franklin Electric motor

Product No.: ZB00067555 Sale group: CEFR EAN: 8596455037767

available in 5 working days
3 pcs
Product availability
  • central warehouse 0 pcs
  • available within 5 working days 3 pcs

4,305.99 €

Maximum flow [l/min]
25
Maximum head [m]
83
Input voltage [V]
3x400
Power output - P2 [kW]
0.37
Rated flow [l/m]
15
Rated head [m]
54
Delivery port ["]
5/4
Pump diameter ["]
4
Maximum immersion depth [m]
150
Drinking water certificate
YES
Float switch
NO
Maximum current [A]
1.10
Maximum liquid temperature [°C]
30
Cable length [m]
1.50
Maximum particle size [mm]
2
Protection [IP]
68
Automatic thermal protection
NO
Dry run protection
NO
Off switch
NO
Speed ​​control
NO
Maximum borehole diameter [mm]
95
Impeller material
noryl
Construction
centrifugal
this variant suits your choice

Franklin Electric 4 VS 1/19 0.55kW 400V submersible pump with Franklin Electric motor

Product No.: ZB00067560 Sale group: CEFR EAN: 8596455037811

available in 5 working days
3 pcs
Product availability
  • central warehouse 0 pcs
  • available within 5 working days 3 pcs

543.46 €

Maximum flow [l/min]
25
Maximum head [m]
118
Input voltage [V]
3x400
Power output - P2 [kW]
0.55
Rated flow [l/m]
15
Rated head [m]
80
Delivery port ["]
5/4
Pump diameter ["]
4
Maximum immersion depth [m]
150
Drinking water certificate
YES
Float switch
NO
Maximum current [A]
1.60
Maximum liquid temperature [°C]
30
Cable length [m]
1.50
Maximum particle size [mm]
2
Protection [IP]
68
Automatic thermal protection
NO
Dry run protection
NO
Off switch
NO
Speed ​​control
NO
Maximum borehole diameter [mm]
95
Impeller material
noryl
Construction
centrifugal
this variant suits your choice

Franklin Electric 4 VS 1/26 0.75kW 400V submersible pump with Franklin Electric motor

Product No.: ZB00067567 Sale group: CEFR EAN: 8596455037880

on demand
check availability
Product availability
  • central warehouse 0 pcs

598.59 €

Check availability

Maximum flow [l/min]
25
Maximum head [m]
156
Input voltage [V]
3x400
Power output - P2 [kW]
0.75
Rated flow [l/m]
15
Rated head [m]
105
Delivery port ["]
5/4
Pump diameter ["]
4
Maximum immersion depth [m]
150
Drinking water certificate
YES
Float switch
NO
Maximum current [A]
2
Maximum liquid temperature [°C]
30
Cable length [m]
1.50
Maximum particle size [mm]
2
Protection [IP]
68
Automatic thermal protection
NO
Dry run protection
NO
Off switch
NO
Speed ​​control
NO
Maximum borehole diameter [mm]
95
Impeller material
noryl
Construction
centrifugal
this variant suits your choice

Franklin Electric 4 VS 1/38 1.1kW 400V submersible pump with Franklin Electric motor

Product No.: ZB00067575 Sale group: CEFR EAN: 8596455037965

on demand
check availability
Product availability
  • central warehouse 0 pcs

740.52 €

Check availability

Maximum flow [l/min]
25
Maximum head [m]
241
Input voltage [V]
3x400
Power output - P2 [kW]
1.10
Rated flow [l/m]
15
Rated head [m]
162
Delivery port ["]
5/4
Pump diameter ["]
4
Maximum immersion depth [m]
150
Drinking water certificate
YES
Float switch
NO
Maximum current [A]
2.80
Maximum liquid temperature [°C]
30
Cable length [m]
1.50
Maximum particle size [mm]
2
Protection [IP]
68
Automatic thermal protection
NO
Dry run protection
NO
Off switch
NO
Speed ​​control
NO
Maximum borehole diameter [mm]
95
Impeller material
noryl
Construction
centrifugal
this variant suits your choice

Product description

APPLICATIONS

  • Municipal water works, fountains and waste water
  • Water distribution and pressure boosting
  • Irrigation and sprinkler systems, water treatment plants, filtration and reverse osmosis
  • Industrial cooling and processing
  • Mining industry, drainage and dewatering
  • Fire-fighting equipment
  • Water supply to and from tanks, reservoir and wells
  • Lifting and distribution of a wide range of liquids
  • Autoclave and cistern charge and discharge
  • Turf and landscape
  • Greenhouses and nurseries
  • Residential and farm wells and drainage
  • Food industry
  • General industry


FEATURES

  • Compact, reliable and suited to operate in horizontal position.
  • Built-in check valve to protect the pump against water hammer risk.
  • Floating impellers to grant a better performance and longer life for the pump against abrasion.
  • The hydraulic design is such to enhance the overall efficiency thus reducing energy consumption and making the pumping systems more cost effective.

Instructions

Technical Specifications

Maximum flow [l/min]
25
Maximum head [m]
68 - 241
Input voltage [V]
3x400
Power output - P2 [kW]
0.37 - 1.10
Rated flow [l/m]
15
Rated head [m]
45 - 162
Delivery port ["]
5/4
Pump diameter ["]
4
Maximum immersion depth [m]
150
Drinking water certificate
YES
Float switch
NO
Maximum current [A]
1.10 - 2.80
Maximum liquid temperature [°C]
30
Cable length [m]
1.50
Maximum particle size [mm]
2
Protection [IP]
68
Automatic thermal protection
NO
Dry run protection
NO
Off switch
NO
Speed ​​control
NO
Maximum borehole diameter [mm]
95
Impeller material
noryl
Construction
centrifugal
