Calpeda NR 32/200 B/A 230/400V 2,2kW 2900rpm, in-line centrifugal pump

Close-coupled, single-impeller, centrifugal pumps; electric motor with extended shaft directly connected to the pump. See more

Technical Specifications

Maximum flow [l/min]
200
Maximum head [m]
42,50
Input voltage [V]
3x400
Power output - P2 [kW]
2,20

Show all Tech Specs

on demand check availability

Goods cannot be purchased online. These are either oversized goods with an individual price of transport or an assortment that can only be purchased on demand. If you are interested in the goods, contact us by email [email protected]

965.34 € VAT included

Not sellable online

Delivery accross EU within 3-7 business days %

Brand:
CALPEDA
Category:
Surface pumps
Product No.:
ZB00048921
Sale group:
CECP
EAN:
8030485974444
Manuf. No.:
70MA0171000

Product variants

  • Technical Specifications
  • Product No.
  • Maximum flow [l/min]
  • Maximum head [m]
  • Input voltage [V]
  • Power output - P2 [kW]
  • Suction port ["]
  • Delivery port ["]
  • Maximum suction lift [m]
  • Maximum current [A]
  • Maximum liquid temperature [°C]
  • Protection [IP]
  • Automatic thermal protection
  • Dry run protection
  • Off switch
  • Speed ​​control
  • Capacitor
  • Pump design
  • Impeller material
  • Availability
  • Price

next

Variant Product No.

Availability

Price (VAT incl.)

Calpeda NR 32/125A 230/400V 0.75kW 2900 rpm, in-line circulation pump

Product No.: ZB00069573 Sale group: CECP Manuf. No.: 70MA0080000

on demand
check availability
Product availability
  • central warehouse 0 pcs

469.58 €

Not sellable online

Maximum flow [l/min]
160
Maximum head [m]
23,30
Input voltage [V]
3x400
Power output - P2 [kW]
0,75
Suction port ["]
DN32
Delivery port ["]
DN32
Maximum suction lift [m]
7
Maximum current [A]
2,20
Maximum liquid temperature [°C]
90
Protection [IP]
54
Automatic thermal protection
NO
Dry run protection
NO
Off switch
NO
Speed ​​control
NO
Capacitor
NO
Pump design
vertical
Impeller material
cast iron

Calpeda NR 32/125B 230/400V 0.55kW 2900 rpm, in-line circulation pump

Product No.: ZB00069572 Sale group: CECP Manuf. No.: 70MA0060000

on demand
check availability
Product availability
  • central warehouse 0 pcs

447.22 €

Not sellable online

Maximum flow [l/min]
140
Maximum head [m]
18,30
Input voltage [V]
3x400
Power output - P2 [kW]
0,55
Suction port ["]
DN32
Delivery port ["]
DN32
Maximum suction lift [m]
7
Maximum current [A]
1,70
Maximum liquid temperature [°C]
90
Protection [IP]
54
Automatic thermal protection
NO
Dry run protection
NO
Off switch
NO
Speed ​​control
NO
Capacitor
NO
Pump design
vertical
Impeller material
cast iron

Calpeda NR 32/160 B/A 230/400V 1,1kW 2900rpm, in-line centrifugal pump

Product No.: ZB00048920 Sale group: CECP EAN: 8030485910503 Manuf. No.: 70MA0111000

on demand
check availability
Product availability
  • central warehouse 0 pcs

606.28 €

Not sellable online

Maximum flow [l/min]
180
Maximum head [m]
28,10
Input voltage [V]
3x400
Power output - P2 [kW]
1,10
Suction port ["]
DN32
Delivery port ["]
DN32
Maximum suction lift [m]
7
Maximum current [A]
2,70
Maximum liquid temperature [°C]
90
Protection [IP]
54
Automatic thermal protection
NO
Dry run protection
NO
Off switch
NO
Speed ​​control
NO
Capacitor
NO
Pump design
vertical
Impeller material
cast iron

Calpeda NR 32/160 A/A 230/400V 1,5kW 2900rpm, in-line centrifugal pump

Product No.: ZB00046511 Sale group: CECP EAN: 8030485916802 Manuf. No.: 70MA0091000

on demand
check availability
Product availability
  • central warehouse 0 pcs

642.74 €

Not sellable online

Maximum flow [l/min]
180
Maximum head [m]
36,80
Input voltage [V]
3x400
Power output - P2 [kW]
1,50
Suction port ["]
DN32
Delivery port ["]
DN32
Maximum suction lift [m]
7
Maximum current [A]
4,30
Maximum liquid temperature [°C]
90
Protection [IP]
54
Automatic thermal protection
NO
Dry run protection
NO
Off switch
NO
Speed ​​control
NO
Capacitor
NO
Pump design
vertical
Impeller material
cast iron

Calpeda NR 32/200 B/A 230/400V 2,2kW 2900rpm, in-line centrifugal pump

Product No.: ZB00048921 Sale group: CECP EAN: 8030485974444 Manuf. No.: 70MA0171000

on demand
check availability
Product availability
  • central warehouse 0 pcs

965.34 €

Not sellable online

Maximum flow [l/min]
200
Maximum head [m]
42,50
Input voltage [V]
3x400
Power output - P2 [kW]
2,20
Suction port ["]
DN32
Delivery port ["]
DN32
Maximum suction lift [m]
7
Maximum current [A]
5,30
Maximum liquid temperature [°C]
90
Protection [IP]
54
Automatic thermal protection
NO
Dry run protection
NO
Off switch
NO
Speed ​​control
NO
Capacitor
NO
Pump design
vertical
Impeller material
cast iron
You are viewing this variant

Calpeda NR 32/200A 230/400V 3,0kW 2900rpm, in-line centrifugal pump

Product No.: ZB00065933 Sale group: CECP EAN: 8030485880028 Manuf. No.: 70MA0150000

on demand
check availability
Product availability
  • central warehouse 0 pcs

1,115.74 €

Not sellable online

Maximum flow [l/min]
250
Maximum head [m]
51,20
Input voltage [V]
3x400
Power output - P2 [kW]
3
Suction port ["]
DN32
Delivery port ["]
DN32
Maximum suction lift [m]
7
Maximum current [A]
6,60
Maximum liquid temperature [°C]
90
Protection [IP]
54
Automatic thermal protection
NO
Dry run protection
NO
Off switch
NO
Speed ​​control
NO
Capacitor
NO
Pump design
vertical
Impeller material
cast iron

Calpeda NR 32/200S/A 400/690V 4,0kW 2900rpm, in-line centrifugal pump

Product No.: ZB00065932 Sale group: CECP EAN: 8030485466130 Manuf. No.: 70MA0141000

on demand
check availability
Product availability
  • central warehouse 0 pcs

1,274.43 €

Not sellable online

Maximum flow [l/min]
280
Maximum head [m]
58
Input voltage [V]
3x400
Power output - P2 [kW]
4
Suction port ["]
DN32
Delivery port ["]
DN32
Maximum suction lift [m]
7
Maximum current [A]
9,40
Maximum liquid temperature [°C]
90
Protection [IP]
54
Automatic thermal protection
NO
Dry run protection
NO
Off switch
NO
Speed ​​control
NO
Capacitor
NO
Pump design
vertical
Impeller material
cast iron

Product description

Applications

  • For clean liquids, without abrasives, which are non-aggressive for the pump materials (contents of solids up to 0.2%).
  • For heating, conditioning, cooling and circulation plants.
  • For civil and industrial applications.
  • When low noise operation is required (n = 1450 rpm).

Instructions

Technical Specifications

Maximum flow [l/min]
200
Maximum head [m]
42,50
Input voltage [V]
3x400
Power output - P2 [kW]
2,20
Suction port ["]
DN32
Delivery port ["]
DN32
Maximum suction lift [m]
7
Maximum current [A]
5,30
Maximum liquid temperature [°C]
90
Protection [IP]
54
Automatic thermal protection
NO
Dry run protection
NO
Off switch
NO
Speed ​​control
NO
Capacitor
NO
Pump design
vertical
Impeller material
cast iron
