Calpeda GQR submersible drainage pump 3x400V

Calpeda GQR submersible drainage pump 3x400V

Technical Specifications

Maximum flow [l/min]
300 - 500
Maximum head [m]
10 - 20
Input voltage [V]
3x400
Power output - P2 [kW]
0.45 - 1.50

Show all Tech Specs

from 540.34 VAT included

Choose variant

Delivery accross EU within 2-4 days %

Brand:
CALPEDA
Category:
Drainage pumps
Product No.:
MAS000254

Product variants

  • Technical Specifications
  • Product No.
  • Maximum flow [l/min]
  • Maximum head [m]
  • Input voltage [V]
  • Power output - P2 [kW]
  • Delivery port ["]
  • Maximum immersion depth [m]
  • Float switch
  • Maximum current [A]
  • Maximum liquid temperature [°C]
  • Cable length [m]
  • Maximum particle size [mm]
  • Protection [IP]
  • Automatic thermal protection
  • Dry run protection
  • Speed ​​control
  • Capacitor
  • Impeller material
  • Construction
  • Grinder
  • Availability
  • Price

next

Variant Product No.

Availability

Price (VAT incl.)

Maximum flow [l/min]
300
Maximum head [m]
10
Input voltage [V]
3x400
Power output - P2 [kW]
0.45
Delivery port ["]
DN40
Maximum immersion depth [m]
5
Float switch
NO
Maximum current [A]
1.20
Maximum liquid temperature [°C]
35
Cable length [m]
10
Maximum particle size [mm]
10
Protection [IP]
X8
Automatic thermal protection
NO
Dry run protection
NO
Speed ​​control
NO
Capacitor
NO
Impeller material
cast iron
Construction
submersible
Grinder
NO
Maximum flow [l/min]
350
Maximum head [m]
12
Input voltage [V]
3x400
Power output - P2 [kW]
0.55
Delivery port ["]
DN40
Maximum immersion depth [m]
5
Float switch
NO
Maximum current [A]
1.40
Maximum liquid temperature [°C]
35
Cable length [m]
10
Maximum particle size [mm]
10
Protection [IP]
X8
Automatic thermal protection
NO
Dry run protection
NO
Speed ​​control
NO
Capacitor
NO
Impeller material
cast iron
Construction
submersible
Grinder
NO

Calpeda GQR 10-14 400V submersible drainage pump, cable 10m

Product No.: ZB00001816 Sale group: CEPJ EAN: 8030485575917 Manuf. No.: 70T71160000

569.65 €

Maximum flow [l/min]
400
Maximum head [m]
14
Input voltage [V]
3x400
Power output - P2 [kW]
0.75
Delivery port ["]
DN40
Maximum immersion depth [m]
5
Float switch
NO
Maximum current [A]
1.60
Maximum liquid temperature [°C]
35
Cable length [m]
10
Maximum particle size [mm]
10
Protection [IP]
X8
Automatic thermal protection
NO
Dry run protection
NO
Speed ​​control
NO
Capacitor
NO
Impeller material
cast iron
Construction
submersible
Grinder
NO

Calpeda GQR 10-16 400V submersible drainage pump, cable 10m

Product No.: ZB00001817 Sale group: CEPJ EAN: 8030485575924 Manuf. No.: 70T71210000

596.25 €

Maximum flow [l/min]
450
Maximum head [m]
16
Input voltage [V]
3x400
Power output - P2 [kW]
0.90
Delivery port ["]
DN40
Maximum immersion depth [m]
5
Float switch
NO
Maximum current [A]
2.30
Maximum liquid temperature [°C]
35
Cable length [m]
10
Maximum particle size [mm]
10
Protection [IP]
X8
Automatic thermal protection
NO
Dry run protection
NO
Speed ​​control
NO
Capacitor
NO
Impeller material
cast iron
Construction
submersible
Grinder
NO

Calpeda GQR 10-18 400V submersible drainage pump, cable 10m

Product No.: ZB00001818 Sale group: CEPJ EAN: 8030485575931 Manuf. No.: 70T71260000

626.64 €

Maximum flow [l/min]
450
Maximum head [m]
18
Input voltage [V]
3x400
Power output - P2 [kW]
1.10
Delivery port ["]
DN40
Maximum immersion depth [m]
5
Float switch
NO
Maximum current [A]
2.80
Maximum liquid temperature [°C]
35
Cable length [m]
10
Maximum particle size [mm]
10
Protection [IP]
X8
Automatic thermal protection
NO
Dry run protection
NO
Speed ​​control
NO
Capacitor
NO
Impeller material
cast iron
Construction
submersible
Grinder
NO
Maximum flow [l/min]
500
Maximum head [m]
20
Input voltage [V]
3x400
Power output - P2 [kW]
1.50
Delivery port ["]
DN40
Maximum immersion depth [m]
5
Float switch
NO
Maximum current [A]
3.80
Maximum liquid temperature [°C]
35
Cable length [m]
10
Maximum particle size [mm]
10
Protection [IP]
X8
Automatic thermal protection
NO
Dry run protection
NO
Speed ​​control
NO
Capacitor
NO
Impeller material
cast iron
Construction
submersible
Grinder
NO

Technical Specifications

Maximum flow [l/min]
300 - 500
Maximum head [m]
10 - 20
Input voltage [V]
3x400
Power output - P2 [kW]
0.45 - 1.50
Delivery port ["]
DN40
Maximum immersion depth [m]
5
Float switch
NO
Maximum current [A]
1.20 - 3.80
Maximum liquid temperature [°C]
35
Cable length [m]
10
Maximum particle size [mm]
10
Protection [IP]
X8
Automatic thermal protection
NO
Dry run protection
NO
Speed ​​control
NO
Capacitor
NO
Impeller material
cast iron
Construction
submersible
Grinder
NO
